K. Tsakalozos

In this post we will see how to automate the deployment of an ASP.NET Core application on an On-Prem Kubernetes cluster. We will base our work on the excellent blog “Deploying ASP.NET Core apps on App Engine” by Mete Atamel. Our contribution would be a) showing how to target public as well as private clouds for Kubernetes deployments, and b) automate the delivery of your software through a basic CI/CD based on Jenkins.

Click here to share this article on LinkedIn »

What will we be using

  • An Ubuntu 16.04 machine
  • git command-line client (installed by sudo apt install git)
  • Internet access
  • $0, yes this is going to be a “look how much you can do for free” kind of blog post

Quick outline

  • Create an ASP.NET Core application on the Ubuntu machine and push the code to GitHub.
  • Package the application in a Docker container and upload it to Docker Hub
  • Spin-up a Kubernetes cluster, the Canonical distribution. Here we will deploy that cluster locally, but you can use any private or public cloud you might have access to.
  • Deploy your application on the Kubernetes cluster and expose it.
  • Deploy Jenkins next to Kubernetes and automate the delivery of your app.

Let’s not waste any time we have a long way ahead of us.

ASP.NET Core applications on Linux

Installing .NET on an Ubuntu 16.04 is as simple as adding a repository and getting dotnet-sdk-2.1.4:

$ curl https://packages.microsoft.com/keys/microsoft.asc | gpg --dearmor > microsoft.gpg
$ sudo mv microsoft.gpg /etc/apt/trusted.gpg.d/microsoft.gpg
$ sudo sh -c 'echo "deb [arch=amd64] https://packages.microsoft.com/repos/microsoft-ubuntu-xenial-prod xenial main" > /etc/apt/sources.list.d/dotnetdev.list'
$ sudo apt-get install apt-transport-https
$ sudo apt-get update
$ sudo apt-get install dotnet-sdk-2.1.4

We can now create our application. It is going to be the template razor application as described in Mete’s codelab and we will not even bother to change the application’s name!

$ mkdir -p ~/workspace/dotnet
$ cd ~/workspace/dotnet
$ dotnet new razor -o HelloWorldAspNetCore
$ cd HelloWorldAspNetCore
$ dotnet run

You should see the application on your browser at http://localhost:5000

Our code will be on a public github repository so go ahead and create an account if you do not already have one (https://github.com). Click the “New repository” button to create a public repository named HelloWorldAspNetCore.

Creating a repository for our code.

Lets add a .gitignore file at the root of our project and push our code:

$ cd ~/workspace/dotnet/HelloWorldAspNetCore
$ wget https://raw.githubusercontent.com/OmniSharp/generator-aspnet/master/templates/gitignore.txt
$ mv gitignore.txt .gitignore
$ git init
$ git add .
$ git commit -m "Initial commit"
$ git remote add origin https://github.com/ktsakalozos/HelloWorldAspNetCore.git
$ git push -u origin master

You can now relax! Your code is safe with github.

Package your application in a Docker container

Installing docker would require adding the respective repository and apt getting docker-ce:

$ sudo apt-get install apt-transport-https ca-certificates curl \
software-properties-common
$ curl -fsSL https://download.docker.com/linux/ubuntu/gpg | sudo apt-key add -
$ sudo add-apt-repository \
"deb [arch=amd64] https://download.docker.com/linux/ubuntu \
$(lsb_release -cs) \
stable"
$ sudo apt-get update
$ sudo apt-get install docker-ce
$ sudo usermod -a -G docker $USER
$ newgrp docker

While we are in the process of setting up docker we might as well register with Docker Hub and create a repository to store our images. Go to https://hub.docker.com and create an account. I will be here waiting :).

After logging in to Docker Hub click on the “Create Repository” button and create a new public repository. That is where we will be pushing our docker images. For the rest of this blog the docker user is “kjackal” and the repository is named “hello-dotnet”. This will make more sense to you shortly.

New docker repository form.

To package our application we first need to ask dotnet to compile our code and gather any dependencies into a folder for later deployment. This is done with:

$ dotnet publish -c Release

Our docker container should package everything under bin/Release/netcoreapp2.0/publish/. We create a `Dockerfile` on the root of our project with the following contents:

$ cd ~/workspace/dotnet/HelloWorldAspNetCore/
$ cat ./Dockerfile
FROM gcr.io/google-appengine/aspnetcore:2.0
ADD ./bin/Release/netcoreapp2.0/publish/ /app
ENV ASPNETCORE_URLS=http://*:${PORT}
WORKDIR /app
ENTRYPOINT [ "dotnet", "HelloWorldAspNetCore.dll"]

Building the container and testing that it works:

$ docker build -t kjackal/hello-dotnet:v1 .
$ docker run -p 8080:8080 kjackal/hello-dotnet:v1

You should see the output at http://localhost:8080 .

It is time to push the first version to Docker Hub:

$ docker login
$ docker push kjackal/hello-dotnet:v1

The Dockerfile should be part of the code so we commit it and push it to the git repository:

$ git add Dockerfile
$ git commit -m "Adding dockerfile"
$ git push origin master

Deploy a Kubernetes Cluster

For the on-prem Kubernetes deployments we will go with Canonical’s solution. The reason being (apart from me being biased) that Canonical offers a seamless and effortless transition from a toy deployment running on your laptop to a full blown production grade Kubernetes deployed on private, public clouds or even on bare metal.

In this blog we show how to deploy Kubernetes and Jenkins on your localhost (laptop/desktop) — just make sure you have at least 8GB of RAM. We first need to have LXD running. LXD is a really powerful type of container based on the same technologies as Docker. Contrary to Docker, LXD containers resemble more to virtual machines (VMs). Lets simplify things and assume from now on that LXD containers are VMs that boot instantly and have no performance overhead!

In the following snippet we install LXD. While initialising ( /snap/bin/lxd init) make sure you go with the defaults but you do not enable ipv6. When asked “What IPv6 address should be used (CIDR subnet notation, “auto” or “none”) [default=auto]?” Reply with “none”.

$ sudo snap install lxd
$ sudo usermod -a -G lxd $USER
$ newgrp lxd
$ /snap/bin/lxd init

At this point we can use either Juju or Conjure-up to deploy Kubernetes. Conjure-up is essentially a wizard sitting on-top of Juju.

As already mentioned by Tim installing Kubernetes with conjure-up is as simple as:

$ sudo snap install conjure-up --classic
$ conjure-up

Canonical Kubernetes comes in two flavours:

  1. kubernetes-core is a cut down version installed in two machines, in our case two LXD containers running on our localhost.
  2. canonical-kubernetes is the full production grade deployment with features such as HA and monitoring.

We will go for kubernetes-core; on the next screen select localhost as the cloud provider. Follow the wizard’s steps till the end and wait for the deployment to finish. For a headless deployment you can do a conjure-up kubernetes-core localhost .

To review the status of our deployment have a look at:

$ juju status

Getting into one of the LXD containers/machines we use juju ssh, for exmple:

$ juju ssh kubernetes-master/0

Inside kubernetes-master under /home/ubuntu you will find a config file you can use for accessing your cluster. We can fetch that file with:

$ juju scp kubernetes-master/0:config .

Conjure-up has already copied the Kubernetes config locally and installed kubectl for us. How nice!

Automate the deployment process, CI/CD

We will be showing a few Jenkins jobs to automate the process of building, packaging and deploying our application. The intention here is to show everything that happens under the hood and not hide behind a flashy UI.

First things first, we need a Jenkins machine.

$ juju deploy jenkins

We deploy Jenkins next to our Kubernetes cluster. This will take some time, you can check the progress of the deployment with juju status.

Next we need to set a password to Jenkins and expose it so we can access its UI on port 8080. Exposing Jenkins is not needed in the localhost deployment which uses LXD containers but we show it here for completeness.

$ juju config jenkins password='your_secure_password'
$ juju expose jenkins

Before we start crafting our jobs we need to configure Jenkins a bit more. I can tell you beforehand our jobs need to sudo run without asking for a password. The easiest way to do that is to edit /etc/sudoers in the Jenkins machine. Here is how we append a line to the sudoers file with Juju:

$ juju run --unit jenkins/0 -- 'sudo echo "jenkins ALL=(ALL) NOPASSWD: ALL" >> /etc/sudoers'

We also know that our Jenkins jobs need to talk to the Kubernetes. To this end Jenkins will need the kubeconfig file. We take the file from the kubernetes-master and place it in our Jenkins machine under /var/tmp:

$ juju scp kubernetes-master/0:config .
$ juju scp config jenkins/0:/var/tmp/

Last part of the configuration, I promise! We know our application will be exposed using Kubernetes NodePort on port 31576. We need to make sure there is no firewall blocking that port and requests can reach it:

$ juju run --application kubernetes-worker -- open-port 31576

We are now ready to create our three main jobs:

Three jobs we will be creating
  • The first Jenkins jobs is the “Install dependencies”. This job is just a shell script installing all software packages needed to a) talk to kubernetes, b) build our ASP.NET application and c) package everything into a docker container. Place the following in a shell script job and run it once:
echo "Installing kubectl"
sudo snap install kubectl --classic
echo "Installing dotnet"
curl https://packages.microsoft.com/keys/microsoft.asc | gpg --dearmor > microsoft.gpg
sudo mv microsoft.gpg /etc/apt/trusted.gpg.d/microsoft.gpg
sudo sh -c 'echo "deb [arch=amd64] https://packages.microsoft.com/repos/microsoft-ubuntu-xenial-prod xenial main" > /etc/apt/sources.list.d/dotnetdev.list'
sudo apt-get install apt-transport-https -y
sudo apt-get update
sudo apt-get install dotnet-sdk-2.1.4 -y
echo "Installing docker"
sudo apt-get install apt-transport-https ca-certificates curl \
software-properties-common -y
curl -fsSL https://download.docker.com/linux/ubuntu/gpg | sudo apt-key add -
sudo add-apt-repository \
"deb [arch=amd64] https://download.docker.com/linux/ubuntu \
$(lsb_release -cs) \
stable"
sudo apt-get update
sudo apt-get install docker-ce -y
  • The second Jenkins job bootstraps the service in Kubernetes. It creates a deployment using the v1 image we created above and it makes sure all operations are recorded ( — record param). This deployment is exposed using NodePort 31576. Place the following in a Jenkins jobs and run it once, remember to update the docker user name (kjackal):
sudo /snap/bin/kubectl --kubeconfig=/var/tmp/config run hello-dotnet \
--image=kjackal/hello-dotnet:v1 --port=8080 --record
echo "apiVersion: v1
kind: Service
metadata:
name: hello-dotnet
spec:
type: NodePort
ports:
- port: 8080
nodePort: 31576
name: http
selector:
run: hello-dotnet" > /tmp/expose.yaml
sudo /snap/bin/kubectl --kubeconfig=/var/tmp/config apply -f /tmp/expose.yaml

Use juju status to find the IP of a kubernetes worker and open a browser at http://<kubernetes-worker-ip>:31576 . Your application is served from Kubernetes! But we are not done yet.

  • Lets create a third job (“Build and release”) that pulls your code from GitHub, compiles it, puts it in a container and deploys that container. Replace the repository and the docker username in the following snippet. Then create a Jenkins job:
rm -rf HelloWorldAspNetCore
git clone https://github.com/ktsakalozos/HelloWorldAspNetCore.git
cd HelloWorldAspNetCore
dotnet publish -c Release
sudo docker login -u kjackal -p ${DOCKER_PASS}
sudo docker build -t kjackal/hello-dotnet:${DOCKER_TAG} .
sudo docker push kjackal/hello-dotnet:${DOCKER_TAG}
sudo /snap/bin/kubectl --kubeconfig=/var/tmp/config set image deployment/hello-dotnet hello-dotnet=kjackal/hello-dotnet:${DOCKER_TAG}

Two parameters are needed: ${DOCKER_TAG} is a string, and ${DOCKER_PASS} holds the docker password of the user (kjackal in this case). You have to tick the checkbox indicating this is a parametrized job and add the two parameters. We are ready! Trigger the job and wait for it to finish. Your code should find its way to our Kubernetes cluster.

You do not believe me? Have a look at the rollout history of our deployment.

$ kubectl rollout history deployment/hello-dotnet

Release from GitHub

Everything looks great so far. Every time we want to release we will login to Jenkins and trigger the “Build and release” job…. Lets try something different. Let’s trigger a release from our code by creating a tag.

Create a “Release from Github” job on Jenkins and have it running periodically every 5 minutes:

Trigger job every 5 minutes

We want this job to look for new tags and if it detects a new one to perform the usual compile, package, deploy cycle. Here is how one such job:

#!/bin/bash
REPO="https://github.com/ktsakalozos/HelloWorldAspNetCore.git"
rm -rf ./HelloWorldAspNetCore
git clone $REPO
cd HelloWorldAspNetCore
# Initialise tags list
if [ ! -f /var/tmp/known-tags ]; then
git tag > /var/tmp/known-tags
echo "Initialising. List of preexisting git tags:"
cat /var/tmp/known-tags
exit 1
fi
mv /var/tmp/known-tags /var/tmp/know-tags.old
git tag > /var/tmp/known-tags
diff /var/tmp/known-tags /var/tmp/know-tags.old
if [ $? == '0' ]; then
echo "No new git tags detected."
exit 2
fi
# We have new tags
last_tag=$(grep -v -f /var/tmp/know-tags.old /var/tmp/known-tags | tail -n 1)
git checkout tags/${last_tag}
echo "Buidling ${last_tag}"
dotnet publish -c Release
sudo docker login -u kjackal -p <replace_with_docker_password>
sudo docker build -t kjackal/hello-dotnet:${last_tag} .
sudo docker push kjackal/hello-dotnet:${last_tag}
sudo /snap/bin/kubectl --kubeconfig=/var/tmp/config set image deployment/hello-dotnet hello-dotnet=kjackal/hello-dotnet:${last_tag}

Make sure you run the this job once so it gets initialised. Afterwords, and every 5 minutes, this job will look at the available tags and fail if no new tags are present.

Lets create a new tag/release now. Go to your GitHub repository click releases -as shown below- and fill up the release form.

Here is where you find the releases you have.
Release form on Github

Within 5 minutes your release will reach Kubernetes! Without you needing to login to Jenkins. Automagically!

A few points to note:

  1. There might be Jenkins plugins for this. But we said we will be looking at what is under the hood without hiding behind a GUI.
  2. You should place your Jenkins jobs on GitHub along with your code.

Where to go from here

So far you have seen the parts of a basic, yet fully functional CI/CD that delivers a .NET application onto any Kubernetes cluster. Each of the steps shown above are subject to improvements and tailoring based on your needs.

  • The ASP.NET application would normally have automated tests. You would want to run these tests in your CI. Travis is a great tool for this purpose and depending on the size and nature of your project it could be free. Alternatively you could setup Jenkins to run these tests as often as you please and report back the result.
  • Look into Helm if you intend to distribute your application instead of offering it as a service hosted by you.
  • Experiment with release strategies and find the one that best suits your needs. Make sure you read through Kubernetes deployment strategies.
  • You could consider using the auto scaling features of Kubernetes.
  • The Kubernetes cluster here is on LXD containers. You should use a cloud either private (eg Openstack) or public. With Conjure-up and Juju the cluster deployment process remains the same regardless of the targeted cloud. You have no excuse.
  • Finally, as you move to a cloud make sure you deploy the Canonical Distribution of Kubernetes instead of kubernetes-core. You will get a more robust deployment with HA features, logging and monitoring.

Resources


Automated Delivery of ASP.NET Core Apps on On-Prem Kubernetes was originally published in ITNEXT on Medium, where people are continuing the conversation by highlighting and responding to this story.

Read more
Dustin Kirkland

  • To date, we've shaved the Bionic (18.04 LTS) minimal images down by over 53%, since Ubuntu 14.04 LTS, and trimmed nearly 100 packages and thousands of files.
  • Feedback welcome here: https://ubu.one/imgSurvey
In last year's AskHN HackerNews post, "Ask HN: What do you want to see in Ubuntu 17.10?", and the subsequent treatment of the data, we noticed a recurring request for "lighter, smaller, more minimal" Ubuntu images.

This is particularly useful for container images (Docker, LXD, Kubernetes, etc.), embedded device environments, and anywhere a developer wants to bootstrap an Ubuntu system from the smallest possible starting point.  Smaller images generally:
  • are subject to fewer security vulnerabilities and subsequent updates
  • reduce overall network bandwidth consumption
  • and require less on disk storage
First, a definition...
"The Ubuntu Minimal Image is the smallest base upon which a user can apt install any package in the Ubuntu archive."
By design, Ubuntu Minimal Images specifically lack the creature comforts, user interfaces and user design experience that have come to define the Ubuntu Desktop and Ubuntu Cloud images.

To date, we've shaved the Bionic (18.04 LTS) minimal images down by over 53%, since Ubuntu 14.04 LTS, and trimmed nearly 100 packages and thousands of files.












Read more
K.Tsakalozos

In our last post we discussed the steps required to build the Canonical Distribution of Kubernetes (CDK). That post should give you a good picture of the components coming together to form a release. Some of these components are architecture agnostic, some not. Here we will update CDK to support IBM’s s390x architecture.

The CDK bundle is made of charms in python running on Ubuntu. That means we are already in a pretty good shape in terms of running on multiple architectures.

However, charms deploy binaries that are architecture specific. These binaries are of two types:

  1. snaps and
  2. juju resources

Snap packages are cross-distribution but unfortunately they are not cross-architecture. We need to build snaps for the architecture we are targeting. Snapped binaries include Kubernetes with its addons as well as etcd.

There are a few other architecture specific binaries that are not snapped yet. Flannel and CNI plugins are consumed by the charms as Juju resources.

Build snaps for s390x

CDK uses snaps to deploy a) Kubernetes binaries b) add-on services and,
c) etcd binaries.

Snaps with Kubernetes binaries

Kubernetes snaps are built using the branch in, https://github.com/juju-solutions/release/tree/rye/snaps/snap. You will need to login to your s390x machine, clone the repository and checkout the right branch:

On your s390x machine:
> git clone https://github.com/juju-solutions/release.git
> cd release
> git checkout rye/snaps
> cd snap

At this point we can build the Kubernetes snaps:

On your s390x machine:
> make KUBE_ARCH=s390x KUBE_VERSION=v1.7.4 kubectl kube-apiserver kube-controller-manager kube-scheduler kubelet kube-proxy kubeadm kubefed

The above will fetch the Kubernetes released binaries from upstream and package them in snaps. You should see a bunch of *_1.7.4_-s390x.snap files in the snap directory.

Snap Kubernetes addons

Apart from the Kubernetes binaries CDK also packages the Kubernetes addons as snaps. The process of building the cdk-addons_1.7.4_s390x.snap is almost identical to the Kubernetes snaps. Clone the cdk-addons repository and make the addons based on the Kubernetes version:

On your s390x machine:
> git clone https://github.com/juju-solutions/cdk-addons.git
> cd cdk-addons
> make KUBE_VERSION=v1.7.4 KUBE_ARCH=s390x

Snap with etcd binaries

The last snap we will need is the snap for etcd. This time we do not have fancy Makafiles but the build process is still very simple:

> git clone https://github.com/tvansteenburgh/etcd-snaps
> cd etcd-snaps/etcd-2.3
> snapcraft — target-arch s390x

At this point you should have etcd_2.3.8_s390x.snap. This snap as well as the addons one and one snap for each of the kubectl kube-apiserver kube-controller-manager kube-scheduler kubelet kube-proxy kubeadm kubefed will be attached to the Kubernetes charms upon release.

Make sure you go through this great post on using Kubernetes snaps.

Build juju resources for s390x

CDK needs to deploy the binaries for CNI and Flannel. These two binaries are not packaged as snaps (they might be in the future), instead they are provided as Juju resources. As these two binaries are architecture specific we need to build them for s390x.

CNI resource

For CNI you need to clone the respective repository, checkout the version you need and compile using a docker environment:

> git clone https://github.com/containernetworking/cni.git cni
> cd cni
> git checkout -f v0.5.1
> docker run — rm -e “GOOS=linux” -e “GOARCH=s390x” -v ${PWD}/cni:/cni golang /bin/bash -c “cd /cni && ./build”

Have a look at how CI creates the tarball needed with the CNI binaries: https://github.com/juju-solutions/kubernetes-jenkins/blob/master/resources/build-cni.sh

Flannel resource

Support for s390x was added from version v0.8.0. Here is the usual cloning and building the repository.

> git clone https://github.com/coreos/flannel.git flannel
> cd flannel
> checkout -f v0.8.0
> make dist/flanneld-s390x

If you look at the CI script for Flannel resource you will see that the tarball also contains the CNI binaries and the etcd client: https://github.com/juju-solutions/kubernetes-jenkins/blob/master/resources/build-flannel.sh

Building etcd:

> git clone https://github.com/coreos/etcd.git etcd
> cd etcd
> git checkout -f v2.3.7
> docker run --rm -e "GOOS=linux" -e "GOARCH=s390x -v ${PWD}/etcd:/etcd golang /bin/bash -c "cd /etcd &&./build"

Update charms

As we already mentioned, charms are written in python so they run on any platform/architecture. We only need to make sure they are fed the right architecture specific binaries to deploy and manage.

Kubernetes charms have a configuration option called channel. Channel points to a fallback snap channel where snaps are fetched from. It is a fallback because snaps are also attached to the charms when releasing them, and priority is given to those attached snaps. Let me a explain how this mechanism works. When releasing a Kubernetes charm you need to provide a resource file for each of the snaps the charm will deploy. If you upload a zero sized file (.snap) the charm will consider this as a dummy snap and try to snap-install the respective snap from the official snap repository. Grabbing the snaps from the official repository works towards a single multi arch charm since the arch specific repository is always available.

For the non snapped binaries we build above (cni and flannel) we need to patch the charms to make sure those binaries are available as Juju resources. In this pull request we add support for multi arch non snapped resources. We add an additional Juju resource for cni built s390x arch.

# In the metadata.yaml file of Kubernetes worker charm
cni-s390x: type: file
etype: file
filename: cni.tgz
description: CNI plugins for amd64

The charm will concatenate “cni-” and the architecture of the system to form the name of the right cni resource. On an amd64 the resource to be used is cni-amd64, on an s390x the cni-s390x is used.

We follow the same approach for the flannel charm. Have a look at the respective pull request.

Build and release

We would need to build the charms, push them to the store, attach the resources and release them. Lets trace these steps for kubernetes-worker:

> cd <path_to_kubernetes_worker_layer>
> charm build
> cd <output_directory_probably_$JUJU_REPOSITORY/builds/kubernetes-worker>
> charm push . cs:~kos.tsakalozos/kubernetes-worker-s390x

You will get a revision number for your charm. In my case it was 0. Lets list the resources we have for that charm:

> charm list-resources cs:~kos.tsakalozos/kubernetes-worker-s390x-0

And attach the resources to the uploaded charm:

> cd <where_your_resources_are>
> charm attach ~kos.tsakalozos/kubernetes-worker-s390x-0 kube-proxy=./kube-proxy.snap
> charm attach ~kos.tsakalozos/kubernetes-worker-s390x-0 kubectl=./kubectl.snap
> charm attach ~kos.tsakalozos/kubernetes-worker-s390x-0 kubelet=./kubelet.snap
> charm attach ~kos.tsakalozos/kubernetes-worker-s390x-0 cni-s390x=./cni-s390x.tgz
> charm attach ~kos.tsakalozos/kubernetes-worker-s390x-0 cni-amd64=./cni-amd64.tgz

Notice how we have to attach one resource per architecture for the cni non-snapped resource. You can try to provide a valid amd64 build for cni but since we are not building a multi arch charm it wouldn’t matter as it will not be used on the targeted s390x platform.

Now let’s release and grant read visibility to everyone:

> charm release cs:~kos.tsakalozos/kubernetes-worker-s390x-0 — channel edge -r cni-s390x-0 -r cni-amd64-0 -r kube-proxy-0 -r kubectl-0 -r kubelet-0
> charm grant cs:~kos.tsakalozos/kubernetes-worker-s390x-0 everyone

We omit building and releasing rest of the charms for brevity.

Summing up

Things have lined up really nice for CDK to support multiple hardware architectures. The architecture specific binaries are well contained into Juju resources and most of them are now shipped as snaps. Building each binary is probably the toughest part in the process outlined above. Each binary has its own dependencies and build process but the scripts linked here reduce the complexity a lot.

In the future we plan to support other architectures. We should end-up with a single bundle that would deploy on any architecture via a juju deploy canonical-kubernetes. You can follow our progress on our trello board. Do not hesitate to reach out and suggest improvements and tell us what architecture you think we should target next.

Read more
K.Tsakalozos

Patch CDK #1: Build & Release

Happens all the time. You often come across a super cool open source project you would gladly contribute but setting up the development environment and learning to patch and release your fixes puts you off. The Canonical Distribution of Kubernetes (CDK) is not an exception. This set of blog posts will shed some light on the most dark secrets of CDK.

Welcome to the CDK patch journey!

What is your Build & Release workflow? (Figure from xkcd)

Build CDK from source

Prerequisits

You would need to have Juju configured and ready to build charms. We will not be covering that in this blog post. Please, follow the official documentation to setup your environment and build you own first charm with layers.

Build the charms

CDK is made of a few charms, namely:

To build each charm you need to spot the top level charm layer and do a `charm build` on it. The links on the above list will get you to the github repository you will need to clone and build. Lets try this out for easyrsa:

> git clone https://github.com/juju-solutions/layer-easyrsa
Cloning into ‘layer-easyrsa’…
remote: Counting objects: 55, done.
remote: Total 55 (delta 0), reused 0 (delta 0), pack-reused 55
Unpacking objects: 100% (55/55), done.
Checking connectivity… done.
> cd ./layer-easyrsa/
> charm build
build: Composing into /home/jackal/workspace/charms
build: Destination charm directory: /home/jackal/workspace/charms/builds/easyrsa
build: Processing layer: layer:basic
build: Processing layer: layer:leadership
build: Processing layer: easyrsa (from .)
build: Processing interface: tls-certificates
proof: OK!

The above builds the easyrsa charm and prints the output directory (/home/jackal/workspace/charms/builds/easyrsa in this case).

Building the kubernetes-* charms is slightly different. As you might already know the kubernetes charm layers are already upstream under cluster/juju/layers. Building the respective charms requires you to clone the kubernetes repository and pass the path to each layer to your invocation of charm build. Let’s build the kubernetes worker layer here:

> git clone https://github.com/kubernetes/kubernetes
Cloning into ‘kubernetes’…
remote: Counting objects: 602553, done.
remote: Compressing objects: 100% (57/57), done.
remote: Total 602553 (delta 18), reused 20 (delta 15), pack-reused 602481
Receiving objects: 100% (602553/602553), 456.97 MiB | 2.91 MiB/s, done.
Resolving deltas: 100% (409190/409190), done.
Checking connectivity… done.
> cd ./kubernetes/
> charm build cluster/juju/layers/kubernetes-worker/
build: Composing into /home/jackal/workspace/charms
build: Destination charm directory: /home/jackal/workspace/charms/builds/kubernetes-worker
build: Processing layer: layer:basic
build: Processing layer: layer:debug
build: Processing layer: layer:snap
build: Processing layer: layer:nagios
build: Processing layer: layer:docker (from ../../../workspace/charms/layers/layer-docker)
build: Processing layer: layer:metrics
build: Processing layer: layer:tls-client
build: Processing layer: layer:nvidia-cuda (from ../../../workspace/charms/layers/nvidia-cuda)
build: Processing layer: kubernetes-worker (from cluster/juju/layers/kubernetes-worker)
build: Processing interface: nrpe-external-master
build: Processing interface: dockerhost
build: Processing interface: sdn-plugin
build: Processing interface: tls-certificates
build: Processing interface: http
build: Processing interface: kubernetes-cni
build: Processing interface: kube-dns
build: Processing interface: kube-control
proof: OK!

During charm build all layers and interfaces referenced recursively starting by the top charm layer are fetched and merged to form your charm. The layers needed for building a charm are specified in a layer.yaml file on the root of the charm’s directory. For example, looking at cluster/juju/layers/kubernetes-worker/layer.yaml we see that the kubernetes worker charm uses the following layers and interfaces:

- 'layer:basic'
- 'layer:debug'
- 'layer:snap'
- 'layer:docker'
- 'layer:metrics'
- 'layer:nagios'
- 'layer:tls-client'
- 'layer:nvidia-cuda'
- 'interface:http'
- 'interface:kubernetes-cni'
- 'interface:kube-dns'
- 'interface:kube-control'

Layers is an awesome way to share operational logic among charms. For instance, the maintainers of the nagios layer have a better understanding of the operational needs of nagios but that does not mean that the authors of the kubernetes charms cannot use it.

charm build will recursively lookup each layer and interface at http://interfaces.juju.solutions/ to figure out where the source is. Each repository is fetched locally and squashed with all the other layers to form a single package, the charm. Go ahead a do a charm build with “-l debug” to see how and when a layer is fetched. It is important to know that if you already have a local copy of a layer under $JUJU_REPOSITORY/layers or interface under $JUJU_REPOSITORY/interfaces charm build will use those local forks instead of fetching them from the registered repositories. This enables charm authors to work on cross layer patches. Note that you might need to rename the directory of your local copy to match exactly the name of the layer or interface.

Building Resources

Charms will install Kubernetes but to do so they need to have the Kubernetes binaries. We package these binaries in snaps so that they are self-contained and deployed in any Linux distribution. Building such binaries is pretty straight forward as long as you know where to find them :)

Here is the repository holding the Kubernetes snaps: https://github.com/juju-solutions/release.git. The branch we want is rye/snaps:

> git clone https://github.com/juju-solutions/release.git
Cloning into ‘release’…
remote: Counting objects: 1602, done.
remote: Total 1602 (delta 0), reused 0 (delta 0), pack-reused 1602
Receiving objects: 100% (1602/1602), 384.69 KiB | 236.00 KiB/s, done.
Resolving deltas: 100% (908/908), done.
Checking connectivity… done.
> cd release
> git checkout rye/snaps
Branch rye/snaps set up to track remote branch rye/snaps from origin.
Switched to a new branch ‘rye/snaps’

Have a look at the README.md inside the snap directory to see how to build the snaps:

> cd snap/
> ./docker-build.sh KUBE_VERSION=v1.7.4

A number of .snap files should be available after the build.

In similar fashion you can build the snap package holding Kubernetes addons. We refer to this package as cdk-addons and it can be found at: https://github.com/juju-solutions/cdk-addons.git

> git clone https://github.com/juju-solutions/cdk-addons.git
Cloning into ‘cdk-addons’…
remote: Counting objects: 408, done.
remote: Total 408 (delta 0), reused 0 (delta 0), pack-reused 408
Receiving objects: 100% (408/408), 51.16 KiB | 0 bytes/s, done.
Resolving deltas: 100% (210/210), done.
Checking connectivity… done.
> cd cdk-addons/
> make

The last resource you will need (which is not packaged as a snap) is the container network interface (cni). Lets grab the repository and get to a release tag:

> git clone https://github.com/containernetworking/cni.git
Cloning into ‘cni’…
remote: Counting objects: 4048, done.
remote: Compressing objects: 100% (5/5), done.
remote: Total 4048 (delta 0), reused 2 (delta 0), pack-reused 4043
Receiving objects: 100% (4048/4048), 1.76 MiB | 613.00 KiB/s, done.
Resolving deltas: 100% (1978/1978), done.
Checking connectivity… done.
> cd cni
> git checkout -f v0.5.1

Build and package the cni resource:

> docker run — rm -e “GOOS=linux” -e “GOARCH=amd64” -v `pwd`:/cni golang /bin/bash -c “cd /cni && ./build”
Building API
Building reference CLI
Building plugins
flannel
tuning
bridge
ipvlan
loopback
macvlan
ptp
dhcp
host-local
noop
> cd ./bin
> tar -cvzf ../cni.tgz *
bridge
cnitool
dhcp
flannel
host-local
ipvlan
loopback
macvlan
noop
ptp
tuning

You should now have a cni.tgz in the root folder of the cni repository.

Two things to note here:
- We do have a CI for building, testing and releasing charms and bundles. In case you want to follow each step of the build process, you can find our CI scripts here: https://github.com/juju-solutions/kubernetes-jenkins
- You do not need to build all resources yourself. You can grab the resources used in CDK from the Juju store. Starting from the canonical-kubernetes bundle you can navigate to any charm shipped. Select one from the very end of the bundle page and then look for the “resources” sidebar on the right. Download any of them, rename it properly and you are ready to use it in your release.

Releasing Your Charms

After patching the charms to match your needs, please, consider submitting a pull request to tell us what you have been up to. Contrary to many other projects you do not need to wait for your PR to get accepted before you can actually make your work public. You can immediately release your work under your own namespace on the store. This is described in detail on the official charm authors documentation. The developers team is often using private namespaces to test PoCs and new features. The main namespace where CDK is released from is “containers”.

Yet, there is one feature you need to be aware of when attaching snaps to your charms. Snaps have their own release cycle and repositories. If you want to use the officially released snaps instead of attaching them to the charms, you can use a dummy zero sized file with the correct extension (.snap) in the place of each snap resource. The snap layer will see that that resource is empty and will try to grab the snap from the official repositories. Using the official snaps is recommended, however, in network restricted environments you might need to attach your own snaps while you deploy the charms.

Why is it this way?

Building CDK is of average difficulty as long as you know how where to look. It is not perfect by any standards and it will probably continue this path. The reason is that there are opposing forces shaping the build processes. This should come as no surprise. As Kubernetes changes rapidly and constantly expands, the build and release process should be flexible enough to include any new artefacts. Consider for example the switch from flannel cni to calico. In our case it is a resource and a charm that need to be updated. A monolithic build script would have been more “elegant” to the outsiders (eg, make CDK), but we would have been hiding a lot under the carpet. CI should be part of the culture of any team and should be owned by the team or else you get disconnected from the end product causing delays and friction. Our build and release process might look a bit “dirty” with a lot of moving parts but it really is not that bad! I managed to highlight the build and release steps in a single blog. Positive feedback also comes from our field engineers. Most of the time CDK deploys out of the box. When our field engineers are called it is either because our customers have a special requirement from the software or they have a “unconventional” environment in which Kubernetes needs to be deployed. Having such a simple and flexible build and release process enables our people to solve a problem on-site and release it tothe Juju store within a couple of hours.

Next steps

This blog post serves as foundation work for what is coming up. The plan is to go over some easy patches so we further demystify how CDK works. Funny thing this post was originally titled “Saying goodbye to my job security”. Cheers!

Read more
K.Tsakalozos

Sometimes we miss the forest for the trees.

It’s all about portability

Take a step back and think about how much of your effort goes into your product’s portability. A lot, I’d wager. You don’t wait to see what hardware your customer is on before you start coding your app. Widely accepted architectures give you a large customer base, so you target those. You skip optimisations in order to maximize compatibility. The language you are using ensures you can move to another platform/architecture.

Packaging your application is also important if you want to broaden your audience. The latest trend here is to use containers such as docker. Essentially containers (much like VMs) are another layer of abstraction for the sake of portability. You can package your app such that it will run anywhere.

https://medium.com/media/e87190de95f6f33f07f75beb4c8e7f39/href

Things go wrong

When you first create a PoC, even a USB stick is enough to distribute it! After that you should take things more seriously. I see products “dockerised” so that they run everywhere, yet the deployment story is limited to a single cloud. You do all the work to deliver your app everywhere only to fail when you actually need to deliver it! It doesn’t make sense — or to put it more accurately it only makes sense in the short term.

The overlooked feature

Canonical Distribution of Kubernetes (CDK) will deploy exactly the same Kubernetes in all major clouds (AWS, GCE, Azure, VMware, Openstack, Joynet), bare metal, or even your local machine (using lxd). When you first evaluate CDK you may think: “I do not need this”, or even “I hate these extra two lines where I decide the cloud provider because I already know I am going full AWS”. At that point you are tempted to take the easy way out and get pinned to a single Kubernetes provider. However, soon you will find yourself in need of feature F from cloud C or Kubernetes version vX.Y.Z. Worse is when your potential customer is on a different platform and you discover the extent of dependencies you have on your provider.

Before you click off this tab thinking I am exaggerating, think about this: the best devops are done by the devs themselves. How easy is it to train all devs to use AWS for spawning containers? It is trivial, right? Suppose you get two more customers, one on Azure and one on GCE. How easy is it to train your team to perform devops against two additional clouds? You now have to deal with three different monitoring and logging mechanisms. That might still be doable since AWS, GCE, and Azure are all well behaved. What if a customer wants their own on-prem cluster? You are done — kiss your portability and velocity goodbye. Your team will be constantly firefighting, chasing after misaligned versions, and emulating features across platforms.

How is it done

Under the hood of CDK you will find Juju. Juju abstracts the concepts of IaaS. It will provision everything from bare metal machines in your rack, to VMs on any major cloud, to lxd containers on your laptop. On top of these units Juju will deploy Kubernetes thus keeping the deployment agnostic to the underlying provider. Two points here:

  1. Juju has been here for years and is used both internally and externally by Canonical to successfully deliver solutions such as Openstack and Big Data.
  2. Since your Kubernetes is built on IaaS cloud offerings you are able to tailor node properties to match your needs. You may also find it is more cost effective.

Also check out Conjure-up, an easy-to-use wizard that will get your Kubernetes cluster up-and-running in minutes.

To conclude

I am sure you have your reasons to “dockerize” your application and then deliver it on a single cloud. It is just counter-intuitive. If you want to make the most from your portability decisions you should consider CDK.

References:

Read more
Dustin Kirkland



Yesterday, I delivered a talk to a lively audience at ContainerWorld in Santa Clara, California.

If I measured "the most interesting slides" by counting "the number of people who took a picture of the slide", then by far "the most interesting slides" are slides 8-11, which pose an answer the question:
"Should I run my PaaS on top of my IaaS, or my IaaS on top of my PaaS"?
In the Ubuntu world, that answer is super easy -- however you like!  At Canonical, we're happy to support:
  1. Kubernetes running on top of Ubuntu OpenStack
  2. OpenStack running on top of Canonical Kubernetes
  3. Kubernetes running along side OpenStack
In all cases, the underlying substrate is perfectly consistent:
  • you've got 1 to N physical or virtual machines
  • which are dynamically provisioned by MAAS or your cloud provider
  • running stable, minimal, secure Ubuntu server image
  • carved up into fast, efficient, independently addressable LXD machine containers
With that as your base, we'll easily to conjure-up a Kubernetes, an OpenStack, or both.  And once you have a Kubernetes or OpenStack, we'll gladly conjure-up one inside the other.


As always, I'm happy to share my slides with you here.  You're welcome to download the PDF, or flip through the embedded slides below.



Cheers,
Dustin

Read more
Dustin Kirkland


A couple of weeks ago, I delivered a talk at the Container Camp UK 2016.  It was an brilliant event, on a beautiful stage at Picturehouse Central in Picadilly Circus in London.

You're welcome to view the slides or download them as a PDF, or watch my talk below.

And for the techies who want to skip the slide fluff and get their hands dirty, setup your OpenStack and LXD and start streamlining your HPC workloads using this guide.




Enjoy,
:-Dustin

Read more
Dustin Kirkland


I'm thrilled to introduce Docker 1.10.3, available on every Ubuntu architecture, for Ubuntu 16.04 LTS, and announce the General Availability of Ubuntu Fan Networking!

That's Ubuntu Docker binaries and Ubuntu Docker images for:
  • armhf (rpi2, et al. IoT devices)
  • arm64 (Cavium, et al. servers)
  • i686 (does anyone seriously still run 32-bit intel servers?)
  • amd64 (most servers and clouds under the sun)
  • ppc64el (OpenPower and IBM POWER8 machine learning super servers)
  • s390x (IBM System Z LinuxOne super uptime mainframes)
That's Docker-Docker-Docker-Docker-Docker-Docker, from the smallest Raspberry Pi's to the biggest IBM mainframes in the world today!  Never more than one 'sudo apt install docker.io' command away.

Moreover, we now have Docker running inside of LXD!  Containers all the way down.  Application containers (e.g. Docker), inside of Machine containers (e.g. LXD), inside of Virtual Machines (e.g. KVM), inside of a public or private cloud (e.g. Azure, OpenStack), running on bare metal (take your pick).

Let's have a look at launching a Docker application container inside of a LXD machine container:

kirkland@x250:~⟫ lxc launch ubuntu-daily:x -p default -p docker
Creating magical-damion
Starting magical-damion
kirkland@x250:~⟫ lxc list | grep RUNNING
| magical-damion | RUNNING | 10.16.4.52 (eth0) | | PERSISTENT | 0 |
kirkland@x250:~⟫ lxc exec magical-damion bash
root@magical-damion:~# apt update >/dev/null 2>&1 ; apt install -y docker.io >/dev/null 2>&1
root@magical-damion:~# docker run -it ubuntu bash
Unable to find image 'ubuntu:latest' locally
latest: Pulling from library/ubuntu
759d6771041e: Pull complete
8836b825667b: Pull complete
c2f5e51744e6: Pull complete
a3ed95caeb02: Pull complete
Digest: sha256:b4dbab2d8029edddfe494f42183de20b7e2e871a424ff16ffe7b15a31f102536
Status: Downloaded newer image for ubuntu:latest
root@0577bd7d5db1:/# ifconfig eth0
eth0 Link encap:Ethernet HWaddr 02:42:ac:11:00:02
inet addr:172.17.0.2 Bcast:0.0.0.0 Mask:255.255.0.0
inet6 addr: fe80::42:acff:fe11:2/64 Scope:Link
UP BROADCAST RUNNING MULTICAST MTU:1500 Metric:1
RX packets:16 errors:0 dropped:0 overruns:0 frame:0
TX packets:8 errors:0 dropped:0 overruns:0 carrier:0
collisions:0 txqueuelen:0
RX bytes:1296 (1.2 KB) TX bytes:648 (648.0 B)


Oh, and let's talk about networking...  We're also pleased to announce the general availability of Ubuntu Fan networking -- specially designed to connect all of your Docker containers spread across your network.  Ubuntu's Fan networking feature is an easy way to make every Docker container on your local network easily addressable by every other Docker host and container on the same network.  It's high performance, super simple, utterly deterministic, and we've tested it on every major public cloud as well as OpenStack and our private networks.

Simply installing Ubuntu's Docker package will also install the ubuntu-fan package, which provides an interactive setup script, fanatic, should you choose to join the Fan.  Simply run 'sudo fanatic' and answer the questions.  You can trivially revert your Fan networking setup easily with 'sudo fanatic deconfigure'.

kirkland@x250:~$ sudo fanatic
Welcome to the fanatic fan networking wizard. This will help you set
up an example fan network and optionally configure docker and/or LXD to
use this network. See fanatic(1) for more details.
Configure fan underlay (hit return to accept, or specify alternative) [10.0.0.0/16]:
Configure fan overlay (hit return to accept, or specify alternative) [250.0.0.0/8]:
Create LXD networking for underlay:10.0.0.0/16 overlay:250.0.0.0/8 [Yn]: n
Create docker networking for underlay:10.0.0.0/16 overlay:250.0.0.0/8 [Yn]: Y
Test docker networking for underlay:10.0.0.45/16 overlay:250.0.0.0/8
(NOTE: potentially triggers large image downloads) [Yn]: Y
local docker test: creating test container ...
34710d2c9a856f4cd7d8aa10011d4d2b3d893d1c3551a870bdb9258b8f583246
test master: ping test (250.0.45.0) ...
test slave: ping test (250.0.45.1) ...
test master: ping test ... PASS
test master: short data test (250.0.45.1 -> 250.0.45.0) ...
test slave: ping test ... PASS
test slave: short data test (250.0.45.0 -> 250.0.45.1) ...
test master: short data ... PASS
test slave: short data ... PASS
test slave: long data test (250.0.45.0 -> 250.0.45.1) ...
test master: long data test (250.0.45.1 -> 250.0.45.0) ...
test master: long data ... PASS
test slave: long data ... PASS
local docker test: destroying test container ...
fanatic-test
fanatic-test
local docker test: test complete PASS (master=0 slave=0)
This host IP address: 10.0.0.45

I've run 'sudo fanatic' here on a couple of machines on my network -- x250 (10.0.0.45) and masterbr (10.0.0.8), and now I'm going to launch a Docker container on each of those two machines, obtain each IP address on the Fan (250.x.y.z), install iperf, and test the connectivity and bandwidth between each of them (on my gigabit home network).  You'll see that we'll get 900mbps+ of throughput:

kirkland@x250:~⟫ sudo docker run -it ubuntu bash
root@c22cf0d8e1f7:/# apt update >/dev/null 2>&1 ; apt install -y iperf >/dev/null 2>&1
root@c22cf0d8e1f7:/# ifconfig eth0
eth0 Link encap:Ethernet HWaddr 02:42:fa:00:2d:00
inet addr:250.0.45.0 Bcast:0.0.0.0 Mask:255.0.0.0
inet6 addr: fe80::42:faff:fe00:2d00/64 Scope:Link
UP BROADCAST RUNNING MULTICAST MTU:1450 Metric:1
RX packets:6423 errors:0 dropped:0 overruns:0 frame:0
TX packets:4120 errors:0 dropped:0 overruns:0 carrier:0
collisions:0 txqueuelen:0
RX bytes:22065202 (22.0 MB) TX bytes:227225 (227.2 KB)

root@c22cf0d8e1f7:/# iperf -c 250.0.8.0
multicast ttl failed: Invalid argument
------------------------------------------------------------
Client connecting to 250.0.8.0, TCP port 5001
TCP window size: 45.0 KByte (default)
------------------------------------------------------------
[ 3] local 250.0.45.0 port 54274 connected with 250.0.8.0 port 5001
[ ID] Interval Transfer Bandwidth
[ 3] 0.0-10.0 sec 1.05 GBytes 902 Mbits/sec

And the second machine:
kirkland@masterbr:~⟫ sudo docker run -it ubuntu bash
root@effc8fe2513d:/# apt update >/dev/null 2>&1 ; apt install -y iperf >/dev/null 2>&1
root@effc8fe2513d:/# ifconfig eth0
eth0 Link encap:Ethernet HWaddr 02:42:fa:00:08:00
inet addr:250.0.8.0 Bcast:0.0.0.0 Mask:255.0.0.0
inet6 addr: fe80::42:faff:fe00:800/64 Scope:Link
UP BROADCAST RUNNING MULTICAST MTU:1450 Metric:1
RX packets:7659 errors:0 dropped:0 overruns:0 frame:0
TX packets:3433 errors:0 dropped:0 overruns:0 carrier:0
collisions:0 txqueuelen:0
RX bytes:22131852 (22.1 MB) TX bytes:189875 (189.8 KB)

root@effc8fe2513d:/# iperf -s
------------------------------------------------------------
Server listening on TCP port 5001
TCP window size: 85.3 KByte (default)
------------------------------------------------------------
[ 4] local 250.0.8.0 port 5001 connected with 250.0.45.0 port 54274
[ ID] Interval Transfer Bandwidth
[ 4] 0.0-10.0 sec 1.05 GBytes 899 Mbits/sec


Finally, let's have another long hard look at the image from the top of this post.  Download it in full resolution to study very carefully what's happening here, because it's pretty [redacted] amazing!


Here, we have a Byobu session, split into 6 panes (Shift-F2 5x Times, Shift-F8 6x times).  In each pane, we have an SSH session to Ubuntu 16.04 LTS servers spread across 6 different architectures -- armhf, arm64, i686, amd64, ppc64el, and s390x.  I used the Shift-F9 key to simultaneously run the same commands in each and every window.  Here are the commands I ran:

clear
lxc launch ubuntu-daily:x -p default -p docker
lxc list | grep RUNNING
uname -a
dpkg -l docker.io | grep docker.io
sudo docker images | grep -m1 ubuntu
sudo docker run -it ubuntu bash
apt update >/dev/null 2>&1 ; apt install -y net-tools >/dev/null 2>&1
ifconfig eth0
exit

That's right.  We just launched Ubuntu LXD containers, as well as Docker containers against every Ubuntu 16.04 LTS architecture.  How's that for Ubuntu everywhere!?!

Ubuntu 16.04 LTS will be one hell of a release!

:-Dustin

Read more
Dustin Kirkland


Ubuntu 16.04 LTS (Xenial) is only a few short weeks away, and with it comes one of the most exciting new features Linux has seen in a very long time...

ZFS -- baked directly into Ubuntu -- supported by Canonical.

What is ZFS?

ZFS is a combination of a volume manager (like LVM) and a filesystem (like ext4, xfs, or btrfs).

ZFS one of the most beloved features of Solaris, universally coveted by every Linux sysadmin with a Solaris background.  To our delight, we're happy to make to OpenZFS available on every Ubuntu system.  Ubuntu's reference guide for ZFS can be found here, and these are a few of the killer features:
  • snapshots
  • copy-on-write cloning
  • continuous integrity checking against data corruption
  • automatic repair
  • efficient data compression.
These features truly make ZFS the perfect filesystem for containers.

What does "support" mean?

  • You'll find zfs.ko automatically built and installed on your Ubuntu systems.  No more DKMS-built modules!
$ locate zfs.ko
/lib/modules/4.4.0-4-generic/kernel/zfs/zfs/zfs.ko
  • You'll see the module loaded automatically if you use it.

$ lsmod | grep zfs
zfs 2801664 11
zunicode 331776 1 zfs
zcommon 57344 1 zfs
znvpair 90112 2 zfs,zcommon
spl 102400 3 zfs,zcommon,znvpair
zavl 16384 1 zfs

  • The user space zfsutils-linux package will be included in Ubuntu Main, with security updates provided by Canonical (as soon as this MIR is completed).
  • As always, industry leading, enterprise class technical support is available from Canonical with Ubuntu Advantage services.

How do I get started?

It's really quite simple!  Here's a few commands to get you up and running with ZFS and LXD in 60 seconds or less.

First, make sure you're running Ubuntu 16.04 (Xenial).

$ head -n1 /etc/issue
Ubuntu Xenial Xerus (development branch) \n \l

Now, let's install lxd and zfsutils-linux, if you haven't already:

$ sudo apt install lxd zfsutils-linux

Next, let's use the interactive lxd init command to setup LXD and ZFS.  In the example below, I'm simply using a sparse, loopback file for the ZFS pool.  For best results (and what I use on my laptop and production servers), it's best to use a raw SSD partition or device.

$ sudo lxd init
Name of the storage backend to use (dir or zfs): zfs
Create a new ZFS pool (yes/no)? yes
Name of the new ZFS pool: lxd
Would you like to use an existing block device (yes/no)? no
Size in GB of the new loop device (1GB minimum): 2
Would you like LXD to be available over the network (yes/no)? no
LXD has been successfully configured.

We can check our ZFS pool now:

$ sudo zpool list
NAME SIZE ALLOC FREE EXPANDSZ FRAG CAP DEDUP HEALTH ALTROOT
lxd 1.98G 450K 1.98G - 0% 0% 1.00x ONLINE -

$ sudo zpool status
pool: lxd
state: ONLINE
scan: none requested
config:

NAME STATE READ WRITE CKSUM
lxd ONLINE 0 0 0
/var/lib/lxd/zfs.img ONLINE 0 0 0
errors: No known data errors

$ lxc config get storage.zfs_pool_name
storage.zfs_pool_name: lxd

Finally, let's import the Ubuntu LXD image, and launch a few containers.  Note how fast containers launch, which is enabled by the ZFS cloning and copy-on-write features:

$ newgrp lxd
$ lxd-images import ubuntu --alias ubuntu
Downloading the GPG key for http://cloud-images.ubuntu.com
Progress: 48 %
Validating the GPG signature of /tmp/tmpa71cw5wl/download.json.asc
Downloading the image.
Image manifest: http://cloud-images.ubuntu.com/server/releases/trusty/release-20160201/ubuntu-14.04-server-cloudimg-amd64.manifest
Image imported as: 54c8caac1f61901ed86c68f24af5f5d3672bdc62c71d04f06df3a59e95684473
Setup alias: ubuntu

$ for i in $(seq 1 5); do lxc launch ubuntu; done
...
$ lxc list
+-------------------------+---------+-------------------+------+-----------+-----------+
| NAME | STATE | IPV4 | IPV6 | EPHEMERAL | SNAPSHOTS |
+-------------------------+---------+-------------------+------+-----------+-----------+
| discordant-loria | RUNNING | 10.0.3.130 (eth0) | | NO | 0 |
+-------------------------+---------+-------------------+------+-----------+-----------+
| fictive-noble | RUNNING | 10.0.3.91 (eth0) | | NO | 0 |
+-------------------------+---------+-------------------+------+-----------+-----------+
| interprotoplasmic-essie | RUNNING | 10.0.3.242 (eth0) | | NO | 0 |
+-------------------------+---------+-------------------+------+-----------+-----------+
| nondamaging-cain | RUNNING | 10.0.3.9 (eth0) | | NO | 0 |
+-------------------------+---------+-------------------+------+-----------+-----------+
| untreasurable-efrain | RUNNING | 10.0.3.89 (eth0) | | NO | 0 |
+-------------------------+---------+-------------------+------+-----------+-----------+

Super easy, right?

Cheers,
:-Dustin

Read more
Dustin Kirkland


There's no shortage of excitement, controversy, and readership, any time you can work "Docker" into a headline these days.  Perhaps a bit like "Donald Trump", but for CIO tech blogs and IT news -- a real hot button.  Hey, look, I even did it myself in the title of this post!

Sometimes an article even starts out about CoreOS, but gets diverted into a discussion about Docker, like this one, where shykes (Docker's founder and CTO) announced that Docker's default image would be moving away from Ubuntu to Alpine Linux.


I have personally been Canonical's business and technical point of contact with Docker Inc, since September of 2013, when I co-presented at an OpenStack Meetup in Austin, Texas, with Ben Golub and Nick Stinemates of Docker.  I can tell you that, along with most of the rest of the Docker community, this casual declaration in an unrelated Hacker News thread, came as a surprise to nearly all of us!

Docker's default container image is certainly Docker's decision to make.  But it would be prudent to examine at a few facts:

(1) Check DockerHub and you may notice that while Busybox (Alpine Linux) has surpassed Ubuntu in the number downloads (66M to 40M), Ubuntu is still by far the most "popular" by number of "stars" -- likes, favorites, +1's, whatever, (3.2K to 499).

(2) Ubuntu's compressed, minimal root tarball is 59 MB, which is what is downloaded over the Internet.  That's different from the 188 MB uncompressed root filesystem, which has been quoted a number of times in the press.

(3) The real magic of Docker is such that you only ever download that base image, one time!  And you only store one copy of the uncompressed root filesystem on your disk! Just once, sudo docker pull ubuntu, on your laptop at home or work, and then launch thousands of images at a coffee shop or airport lounge with its spotty wifi.  Build derivative images, FROM ubuntu, etc. and you only ever store the incremental differences.

Actually, I encourage you to test that out yourself...  I just launched a t2.micro -- Amazon's cheapest instance type with the lowest networking bandwidth.  It took 15.938s to sudo apt install docker.io.  And it took 9.230s to sudo docker pull ubuntu.  It takes less time to download Ubuntu than to install Docker!

ubuntu@ip-172-30-0-129:~⟫ time sudo apt install docker.io -y
...
real 0m15.938s
user 0m2.146s
sys 0m0.913s

As compared to...

ubuntu@ip-172-30-0-129:~⟫ time sudo docker pull ubuntu
latest: Pulling from ubuntu
f15ce52fc004: Pull complete
c4fae638e7ce: Pull complete
a4c5be5b6e59: Pull complete
8693db7e8a00: Pull complete
ubuntu:latest: The image you are pulling has been verified. Important: image verification is a tech preview feature and should not be relied on to provide security.
Digest: sha256:457b05828bdb5dcc044d93d042863fba3f2158ae249a6db5ae3934307c757c54
Status: Downloaded newer image for ubuntu:latest
real 0m9.230s
user 0m0.021s
sys 0m0.016s

Now, sure, it takes even less than that to download Alpine Linux (0.747s by my test), but again you only ever do that once!  After you have your initial image, launching Docker containers take the exact same amount of time (0.233s) and identical storage differences.  See:

ubuntu@ip-172-30-0-129:/tmp/docker⟫ time sudo docker run alpine /bin/true
real 0m0.233s
user 0m0.014s
sys 0m0.001s
ubuntu@ip-172-30-0-129:/tmp/docker⟫ time sudo docker run ubuntu /bin/true
real 0m0.234s
user 0m0.012s
sys 0m0.002s

(4) I regularly communicate sincere, warm congratulations to our friends at Docker Inc, on its continued growth.  shykes publicly mentioned the hiring of the maintainer of Alpine Linux in that Hacker News post.  As a long time Linux distro developer myself, I have tons of respect for everyone involved in building a high quality Linux distribution.  In fact, Canonical employs over 700 people, in 44 countries, working around the clock, all calendar year, to make Ubuntu the world's most popular Linux OS.  Importantly, that includes a dedicated security team that has an outstanding track record over the last 12 years, keeping Ubuntu servers, clouds, desktops, laptops, tablets, and phones up-to-date and protected against the latest security vulnerabilities.  I don't know personally Natanael, but I'm intimately aware of what a spectacular amount of work it is to maintain and secure an OS distribution, as it makes its way into enterprise and production deployments.  Good luck!

(5) There are currently 5,854 packages available via apk in Alpine Linux (sudo docker run alpine apk search -v).  There are 8,862 packages in Ubuntu Main (officially supported by Canonical), and 53,150 binary packages across all of Ubuntu Main, Universe, Restricted, and Multiverse, supported by the greater Ubuntu community.  Nearly all 50,000+ packages are updated every 6 months, on time, every time, and we release an LTS version of Ubuntu and the best of open source software in the world every 2 years.  Like clockwork.  Choice.  Velocity.  Stability.  That's what Ubuntu brings.

Docker holds a special place in the Ubuntu ecosystem, and Ubuntu has been instrumental in Docker's growth over the last 3 years.  Where we go from here, is largely up to the cross-section of our two vibrant communities.

And so I ask you honestly...what do you want to see?  How would you like to see Docker and Ubuntu operate together?

I'm Canonical's Product Manager for Ubuntu Server, I'm responsible for Canonical's relationship with Docker Inc, and I will read absolutely every comment posted below.

Cheers,
:-Dustin

p.s. I'm speaking at Container Summit in New York City today, and wrote this post from the top of the (inspiring!) One World Observatory at the World Trade Center this morning.  Please come up and talk to me, if you want to share your thoughts (at Container Summit, not the One World Observatory)!


Read more
Dustin Kirkland


I delivered a presentation and an exciting live demo in San Francisco this week at the Container Summit (organized by Joyent).

It was professionally recorded by the A/V crew at the conference.  The live demo begins at the 25:21 mark.


You can also find the slide deck embedded below and download the PDFs from here.


Cheers,
:-Dustin

Read more
Dustin Kirkland


Canonical is delighted to sponsor ContainerCon 2015, a Linux Foundation event in Seattle next week, August 17-19, 2015. It's quite exciting to see the A-list of sponsors, many of them newcomers to this particular technology, teaming with energy around containers.

From chroots to BSD Jails and Solaris Zones, the concepts behind containers were established decades ago, and in fact traverse the spectrum of server operating systems. At Canonical, we've been working on containers in Ubuntu for more than half a decade, providing a home and resources for stewardship and maintenance of the upstream Linux Containers (LXC) project since 2010.

Last year, we publicly shared our designs for LXD -- a new stratum on top of LXC that endows the advantages of a traditional hypervisor into the faster, more efficient world of containers.

Those designs are now reality, with the open source Golang code readily available on Github, and Ubuntu packages available in a PPA for all supported releases of Ubuntu, and already in the Ubuntu 15.10 beta development tree. With ease, you can launch your first LXD containers in seconds, following this simple guide.

LXD is a persistent daemon that provides a clean RESTful interface to manage (start, stop, clone, migrate, etc.) any of the containers on a given host.

Hosts running LXD are handily federated into clusters of container hypervisors, and can work as Nova Compute nodes in OpenStack, for example, delivering Infrastructure-as-a-Service cloud technology at lower costs and greater speeds.

Here, LXD and Docker are quite complementary technologies. LXD furnishes a dynamic platform for "system containers" -- containers that behave like physical or virtual machines, supplying all of the functionality of a full operating system (minus the kernel, which is shared with the host). Such "machine containers" are the core of IaaS clouds, where users focus on instances with compute, storage, and networking that behave like traditional datacenter hardware.

LXD runs perfectly well along with Docker, which supplies a framework for "application containers" -- containers that enclose individual processes that often relate to one another as pools of micro services and deliver complex web applications.

Moreover, the Zen of LXD is the fact that the underlying container implementation is actually decoupled from the RESTful API that drives LXD functionality. We are most excited to discuss next week at ContainerCon our work with Microsoft around the LXD RESTful API, as a cross-platform container management layer.

Ben Armstrong, a Principal Program Manager Lead at Microsoft on the core virtualization and container technologies, has this to say:
“As Microsoft is working to bring Windows Server Containers to the world – we are excited to see all the innovation happening across the industry, and have been collaborating with many projects to encourage and foster this environment. Canonical’s LXD project is providing a new way for people to look at and interact with container technologies. Utilizing ‘system containers’ to bring the advantages of container technology to the core of your cloud infrastructure is a great concept. We are looking forward to seeing the results of our engagement with Canonical in this space.”
Finally, if you're in Seattle next week, we hope you'll join us for the technical sessions we're leading at ContainerCon 2015, including: "Putting the D in LXD: Migration of Linux Containers", "Container Security - Past, Present, and Future", and "Large Scale Container Management with LXD and OpenStack". Details are below.
Date: Monday, August 17 • 2:20pm - 3:10pm
Title: Large Scale Container Management with LXD and OpenStack
Speaker: Stéphane Graber
Abstracthttp://sched.co/3YK6
Location: Grand Ballroom B
Schedulehttp://sched.co/3YK6
Date: Wednesday, August 19 10:25am-11:15am
Title: Putting the D in LXD: Migration of Linux Containers
Speaker: Tycho Andersen
Abstract: http://sched.co/3YTz
Location: Willow A
Schedule: http://sched.co/3YTz
Date: Wednesday, August 19 • 3:00pm - 3:50pm
Title: Container Security - Past, Present and Future
Speaker: Serge Hallyn
Abstract: http://sched.co/3YTl
Location: Ravenna
Schedule: http://sched.co/3YTl
Cheers,
Dustin

Read more
Dustin Kirkland

tl;dr:  Your Ubuntu-based container is not a copyright violation.  Nothing to see here.  Carry on.
I am speaking for my employer, Canonical, when I say you are not violating our policies if you use Ubuntu with Docker in sensible, secure ways.  Some have claimed otherwise, but that’s simply sensationalist and untrue.

Canonical publishes Ubuntu images for Docker specifically so that they will be useful to people. You are encouraged to use them! We see no conflict between our policies and the common sense use of Docker.

Going further, we distribute Ubuntu in many different signed formats -- ISOs, root tarballs, VMDKs, AMIs, IMGs, Docker images, among others.  We take great pride in this work, and provide them to the world at large, on ubuntu.com, in public clouds like AWS, GCE, and Azure, as well as in OpenStack and on DockerHub.  These images, and their signatures, are mirrored by hundreds of organizations all around the world. We would not publish Ubuntu in the DockerHub if we didn’t hope it would be useful to people using the DockerHub. We’re delighted for you to use them in your public clouds, private clouds, and bare metal deployments.

Any Docker user will recognize these, as the majority of all Dockerfiles start with these two words....

FROM ubuntu

In fact, we gave away hundreds of these t-shirts at DockerCon.


We explicitly encourage distribution and redistribution of Ubuntu images and packages! We also embrace a very wide range of community remixes and modifications. We go further than any other commercially supported Linux vendor to support developers and community members scratching their itches. There are dozens of such derivatives and many more commercial initiatives based on Ubuntu - we are definitely not trying to create friction for people who want to get stuff done with Ubuntu.

Our policy exists to ensure that when you receive something that claims to be Ubuntu, you can trust that it will work to the same standard, regardless of where you got it from. And people everywhere tell us they appreciate that - when they get Ubuntu on a cloud or as a VM, it works, and they can trust it.  That concept is actually hundreds of years old, and we’ll talk more about that in a minute....


So, what do I mean by “sensible use” of Docker? In short - secure use of Docker. If you are using a Docker container then you are effectively giving the producer of that container ‘root’ on your host. We can safely assume that people sharing an Ubuntu docker based container know and trust one another, and their use of Ubuntu is explicitly covered as personal use in our policy. If you trust someone to give you a Docker container and have root on your system, then you can handle the risk that they inadvertently or deliberately compromise the integrity or reliability of your system.

Our policy distinguishes between personal use, which we can generalise to any group of collaborators who share root passwords, and third party redistribution, which is what people do when they exchange OS images with strangers.

Third party redistribution is more complicated because, when things go wrong, there’s a real question as to who is responsible for it. Here’s a real example: a school district buys laptops for all their students with free software. A local supplier takes their preferred Linux distribution and modifies parts of it (like the kernel) to work on their hardware, and sells them all the PCs. A month later, a distro kernel update breaks all the school laptops. In this case, the Linux distro who was not involved gets all the bad headlines, and the free software advocates who promoted the whole idea end up with egg on their faces.

We’ve seen such cases in real hardware, and in public clouds and other, similar environments.  Digital Ocean very famously published some modified and very broken Ubuntu images, outside of Canonical's policies.  That's inherently wrong, and easily avoidable.

So we simply say, if you’re going to redistribute Ubuntu to third parties who are trusting both you and Ubuntu to get it right, come and talk to Canonical and we’ll work out how to ensure everybody gets what they want and need.

Here’s a real exercise I hope you’ll try...

  1. Head over to your local purveyor of fine wines and liquors.
  2. Pick up a nice bottle of Champagne, Single Malt Scotch Whisky, Kentucky Straight Bourbon Whiskey, or my favorite -- a rare bottle of Lambic Oude Gueze.
  3. Carefully check the label, looking for a seal of Appellation d'origine contrôlée.
  4. In doing so, that bottle should earn your confidence that it was produced according to strict quality, format, and geographic standards.
  5. Before you pop the cork, check the seal, to ensure it hasn’t been opened or tampered with.  Now, drink it however you like.
  6. Pour that Champagne over orange juice (if you must).  Toss a couple ice cubes in your Scotch (if that’s really how you like it).  Pour that Bourbon over a Coke (if that’s what you want).
  7. Enjoy however you like -- straight up or mixed to taste -- with your own guests in the privacy of your home.  Just please don’t pour those concoctions back into the bottle, shove a cork in, put them back on the shelf at your local liquor store and try to pass them off as Champagne/Scotch/Bourbon.


Rather, if that’s really what you want to do -- distribute a modified version of Ubuntu -- simply contact us and ask us first (thanks for sharing that link, mjg59).  We have some amazing tools that can help you either avoid that situation entirely, or at least let’s do everyone a service and let us help you do it well.

Believe it or not, we’re really quite reasonable people!  Canonical has a lengthy, public track record, donating infrastructure and resources to many derivative Ubuntu distributions.  Moreover, we’ve successfully contracted mutually beneficial distribution agreements with numerous organizations and enterprises. The result is happy users and happy companies.

FROM ubuntu,
Dustin

The one and only Champagne region of France

Read more
Dustin Kirkland


As you probably remember from grade school math class, primes are numbers that are only divisible by 1 and themselves.  2, 3, 5, 7, and 11 are the first 5 prime numbers, for example.

Many computer operations, such as public-key cryptography, depends entirely on prime numbers.  In fact, RSA encryption, invented in 1978, uses a modulo of a product of two very large primes for encryption and decryption.  The security of asymmetric encryption is tightly coupled with the computational difficulty in factoring large numbers.  I actually use prime numbers as the status update intervals in Byobu, in order to improve performance and distribute the update spikes.

Euclid proved that there are infinitely many prime numbers around 300 BC.  But the Prime Number Theorem (proven in the 19th century) says that the probability of any number is prime is inversely proportional to its number of digits.  That means that larger prime numbers are notoriously harder to find, and it gets harder as they get bigger!
What's the largest known prime number in the world?

Well, it has 17,425,170 decimal digits!  If you wanted to print it out, size 11 font, it would take 6,543 pages -- or 14 reams of paper!

That number is actually one less than a very large power of 2.  257,885,161-1.  It was discovered by Curtis Cooper on January 25, 2013, on an Intel Core2 Duo.

Actually, each of the last 14 record largest prime numbers discovered (between 1996 and today) have been of that form, 2P-1.  Numbers of that form are called Mersenne Prime Numbers, named after Friar Marin Mersenne, a French priest who studied them in the 1600s.


Friar Mersenne's work continues today in the form of the Great Internet Mersenne Prime Search, and the mprime program, which has been used to find those 14 huge prime numbers since 1996.

mprime is a massive parallel, cpu scavenging utility, much like SETI@home or the Protein Folding Project.  It runs in the background, consuming resources, working on its little piece of the problem.  mprime is open source code, and also distributed as a statically compiled binary.  And it will make a fine example of how to package a service into a Docker container, a Juju charm, and a Snappy snap.


Docker Container

First, let's build the Docker container, which will serve as our fundamental building block.  You'll first need to download the mprime tarball from here.  Extract it, and the directory structure should look a little like this (or you can browse it here):

├── license.txt
├── local.txt
├── mprime
├── prime.log
├── prime.txt
├── readme.txt
├── results.txt
├── stress.txt
├── undoc.txt
├── whatsnew.txt
└── worktodo.txt

And then, create a Dockerfile, that copies the files we need into the image.  Here's our example.

FROM ubuntu
MAINTAINER Dustin Kirkland email@example.com
COPY ./mprime /opt/mprime/
COPY ./license.txt /opt/mprime/
COPY ./prime.txt /opt/mprime/
COPY ./readme.txt /opt/mprime/
COPY ./stress.txt /opt/mprime/
COPY ./undoc.txt /opt/mprime/
COPY ./whatsnew.txt /opt/mprime/
CMD ["/opt/mprime/mprime", "-w/opt/mprime/"]

Now, build your Docker image with:

$ sudo docker build .
Sending build context to Docker daemon 36.02 MB
Sending build context to Docker daemon
Step 0 : FROM ubuntu
...
Successfully built de2e817b195f

Then publish the image to Dockerhub.

$ sudo docker push kirkland/mprime

You can see that image, which I've publicly shared here: https://registry.hub.docker.com/u/kirkland/mprime/



Now you can run this image anywhere you can run Docker.

$ sudo docker run -d kirkland/mprime

And verify that it's running:

$ sudo docker ps
CONTAINER ID IMAGE COMMAND CREATED STATUS PORTS NAMES
c9233f626c85 kirkland/mprime:latest "/opt/mprime/mprime 24 seconds ago Up 23 seconds furious_pike

Juju Charm

So now, let's create a Juju Charm that uses this Docker container.  Actually, we're going to create a subordinate charm.  Subordinate services in Juju are often monitoring and logging services, things that run along side primary services.  Something like mprime is a good example of something that could be a subordinate service, attached to one or many other services in a Juju model.

Our directory structure for the charm looks like this (or you can browse it here):

└── trusty
└── mprime
├── config.yaml
├── copyright
├── hooks
│   ├── config-changed
│   ├── install
│   ├── juju-info-relation-changed
│   ├── juju-info-relation-departed
│   ├── juju-info-relation-joined
│   ├── start
│   ├── stop
│   └── upgrade-charm
├── icon.png
├── icon.svg
├── metadata.yaml
├── README.md
└── revision
3 directories, 15 files

The three key files we should look at here are metadata.yaml, hooks/install and hooks/start:

$ cat metadata.yaml
name: mprime
summary: Search for Mersenne Prime numbers
maintainer: Dustin Kirkland
description: |
A Mersenne prime is a prime of the form 2^P-1.
The first Mersenne primes are 3, 7, 31, 127
(corresponding to P = 2, 3, 5, 7).
There are only 48 known Mersenne primes, and
the 13 largest known prime numbers in the world
are all Mersenne primes.
This charm uses a Docker image that includes the
statically built, 64-bit Linux binary mprime
which will consume considerable CPU and Memory,
searching for the next Mersenne prime number.
See http://www.mersenne.org/ for more details!
tags:
- misc
subordinate: true
requires:
juju-info:
interface: juju-info
scope: container

And:

$ cat hooks/install
#!/bin/bash
apt-get install -y docker.io
docker pull kirkland/mprime

And:

$ cat hooks/start
#!/bin/bash
service docker restart
docker run -d kirkland/mprime

Now, we can add the mprime service to any other running Juju service.  As an example here, I'll --bootstrap, deploy the Apache2 charm, and attach mprime to it.

$ juju bootrap
$ juju deploy apache2
$ juju deploy cs:~kirkland/mprime
$ juju add-relation apache2 mprime

Looking at our services, we can see everything deployed and running here:

$ juju status
services:
apache2:
charm: cs:trusty/apache2-14
exposed: false
service-status:
current: unknown
since: 20 Jul 2015 11:55:59-05:00
relations:
juju-info:
- mprime
units:
apache2/0:
workload-status:
current: unknown
since: 20 Jul 2015 11:55:59-05:00
agent-status:
current: idle
since: 20 Jul 2015 11:56:03-05:00
version: 1.24.2
agent-state: started
agent-version: 1.24.2
machine: "1"
public-address: 23.20.147.158
subordinates:
mprime/0:
workload-status:
current: unknown
since: 20 Jul 2015 11:58:52-05:00
agent-status:
current: idle
since: 20 Jul 2015 11:58:56-05:00
version: 1.24.2
agent-state: started
agent-version: 1.24.2
upgrading-from: local:trusty/mprime-1
public-address: 23.20.147.158
mprime:
charm: local:trusty/mprime-1
exposed: false
service-status: {}
relations:
juju-info:
- apache2
subordinate-to:
- apache2


Snappy Ubuntu Core Snap

Finally, let's build a Snap.  Snaps are applications that run in Ubuntu's transactional, atomic OS, Snappy Ubuntu Core.

We need the simple directory structure below (or you can browse it here):

├── meta
│   ├── icon.png
│   ├── icon.svg
│   ├── package.yaml
│   └── readme.md
└── start.sh
1 directory, 5 files

The package.yaml describes what we're actually building, and what capabilities the service needs.  It looks like this:

name: mprime
vendor: Dustin Kirkland
architecture: [amd64]
icon: meta/icon.png
version: 28.5-11
frameworks:
- docker
services:
- name: mprime
description: "Search for Mersenne Prime Numbers"
start: start.sh
caps:
- docker_client
- networking

And the start.sh launches the service via Docker.

#!/bin/sh
PATH=$PATH:/apps/docker/current/bin/
docker rm -v -f mprime
docker run --name mprime -d kirkland/mprime
docker wait mprime

Now, we can build the snap like so:

$ snappy build .
Generated 'mprime_28.5-11_amd64.snap' snap
$ ls -halF *snap
-rw-rw-r-- 1 kirkland kirkland 9.6K Jul 20 12:38 mprime_28.5-11_amd64.snap

First, let's install the Docker framework, upon which we depend:

$ snappy-remote --url ssh://snappy-nuc install docker
=======================================================
Installing docker from the store
Installing docker
Name Date Version Developer
ubuntu-core 2015-04-23 2 ubuntu
docker 2015-07-20 1.6.1.002
webdm 2015-04-23 0.5 sideload
generic-amd64 2015-04-23 1.1
=======================================================

And now, we can install our locally built Snap.
$ snappy-remote --url ssh://snappy-nuc install mprime_28.5-11_amd64.snap
=======================================================
Installing mprime_28.5-11_amd64.snap from local environment
Installing /tmp/mprime_28.5-11_amd64.snap
2015/07/20 17:44:26 Signature check failed, but installing anyway as requested
Name Date Version Developer
ubuntu-core 2015-04-23 2 ubuntu
docker 2015-07-20 1.6.1.002
mprime 2015-07-20 28.5-11 sideload
webdm 2015-04-23 0.5 sideload
generic-amd64 2015-04-23 1.1
=======================================================

Alternatively, you can install the snap directly from the Ubuntu Snappy store, where I've already uploaded the mprime snap:

$ snappy-remote --url ssh://snappy-nuc install mprime.kirkland
=======================================================
Installing mprime.kirkland from the store
Installing mprime.kirkland
Name Date Version Developer
ubuntu-core 2015-04-23 2 ubuntu
docker 2015-07-20 1.6.1.002
mprime 2015-07-20 28.5-11 kirkland
webdm 2015-04-23 0.5 sideload
generic-amd64 2015-04-23 1.1
=======================================================

Conclusion

How long until this Docker image, Juju charm, or Ubuntu Snap finds a Mersenne Prime?  Almost certainly never :-)  I want to be clear: that was never the point of this exercise!

Rather I hope you learned how easy it is to run a Docker image inside either a Juju charm or an Ubuntu snap.  And maybe learned something about prime numbers along the way ;-)

Join us in #docker, #juju, and #snappy on irc.freenode.net.

Cheers,
Dustin

Read more
Dustin Kirkland

652 Linux containers running on a Laptop?  Are you kidding me???

A couple of weeks ago, at the OpenStack Summit in Vancouver, Canonical released the results of some scalability testing of Linux containers (LXC) managed by LXD.

Ryan Harper and James Page presented their results -- some 536 Linux containers on a very modest little Intel server (16GB of RAM), versus 37 KVM virtual machines.

Ryan has published the code he used for the benchmarking, and I've used to to reproduce the test on my dev laptop (Thinkpad x230, 16GB of RAM, Intel i7-3520M).

I managed to pack a whopping 652 Ubuntu 14.04 LTS (Trusty) containers on my Ubuntu 15.04 (Vivid) laptop!


The system load peaked at 1056 (!!!), but I was using merely 56% of 15.4GB of system memory.  Amazingly, my Unity desktop and Byobu command line were still perfectly responsive, as were the containers that I ssh'd into.  (Aside: makes me wonder if the Linux system load average is accounting for container process correctly...)


Check out the process tree for a few hundred system containers here!

As for KVM, I managed to launch 31 virtual machines without KSM enabled, and 65 virtual machines with KSM enabled and working hard.  So that puts somewhere between 10x - 21x as many containers as virtual machines on the same laptop.

You can now repeat these tests, if you like.  Please share your results with #LXD on Google+ or Twitter!

I'd love to see someone try this in AWS, anywhere from an m3.small to an r3.8xlarge, and share your results ;-)

Density test instructions

## Install lxd
$ sudo add-apt-repository ppa:ubuntu-lxc/lxd-git-master
$ sudo apt-get update
$ sudo apt-get install -y lxd bzr
$ cd /tmp
## At this point, it's a good idea to logout/login or reboot
## for your new group permissions to get applied
## Grab the tests, disable the tools download
$ bzr branch lp:~raharper/+junk/density-check
$ cd density-check
$ mkdir lxd_tools
## Periodically squeeze your cache
$ sudo bash -x -c 'while true; do sleep 30; \
echo 3 | sudo tee /proc/sys/vm/drop_caches; \
free; done' &
## Run the LXD test
$ ./density-check-lxd --limit=mem:512m --load=idle release=trusty arch=amd64
## Run the KVM test
$ ./density-check-kvm --limit=mem:512m --load=idle release=trusty arch=amd64

As for the speed-of-launch test, I'll cover that in a follow-up post!

Can you contain your excitement?

Cheers!
Dustin

Read more
Dustin Kirkland

Gratuitous picture of my pets, the day after we rescued them
The PetName libraries (Shell, Python, Golang) can generate infinite combinations of human readable UUIDs


Some Background

In March 2014, when I first started looking after MAAS as a product manager, I raised a minor feature request in Bug #1287224, noting that the random, 5-character hostnames that MAAS generates are not ideal. You can't read them or pronounce them or remember them easily. I'm talking about hostnames like: sldna, xwknd, hwrdz or wkrpb. From that perspective, they're not very friendly. Certainly not very Ubuntu.

We're not alone, in that respect. Amazon generates forgettable instance names like i-15a4417c, along with most virtual machine and container systems.


Meanwhile, there is a reasonably well-known concept -- Zooko's Triangle -- which says that names should be:
  • Human-meaningful: The quality of meaningfulness and memorability to the users of the naming system. Domain names and nicknaming are naming systems that are highly memorable
  • Decentralized: The lack of a centralized authority for determining the meaning of a name. Instead, measures such as a Web of trust are used.
  • Secure: The quality that there is one, unique and specific entity to which the name maps. For instance, domain names are unique because there is just one party able to prove that they are the owner of each domain name.
And, of course we know what XKCD has to say on a somewhat similar matter :-)

So I proposed a few different ways of automatically generating those names, modeled mostly after Ubuntu's beloved own code naming scheme -- Adjective Animal. To get the number of combinations high enough to model any reasonable MAAS user, though, we used Adjective Noun instead of Adjective Animal.

I collected a Adjective list and a Noun list from a blog run by moms, in the interest of having a nice, soft, friendly, non-offensive source of words.

For the most part, the feature served its purpose. We now get memorable, pronounceable names. However, we get a few odd balls in there from time to time. Most are humorous. But some combinations would prove, in fact, to be inappropriate, or perhaps even offensive to some people.

Accepting that, I started thinking about other solutions.

In the mean time, I realized that Docker had recently launched something similar, their NamesGenerator, which pairs an Adjective with a Famous Scientist's Last Name (except they have explicitly blacklisted boring_wozniak, because "Steve Wozniak is not boring", of course!).


Similarly, Github itself now also "suggests" random repo names.



I liked one part of the Docker approach better -- the use of proper names, rather than random nouns.

On the other hand, their approach is hard-coded into the Docker Golang source itself, and not usable or portable elsewhere, easily.

Moreover, there's only a few dozen Adjectives (57) and Names (76), yielding only about 4K combinations (4332) -- which is not nearly enough for MAAS's purposes, where we're shooting for 16M+, with minimal collisions (ie, covering a Class A network).

Introducing the PetName Libraries

I decided to scrap the Nouns list, and instead build a Names list. I started with Last Names (like Docker), but instead focused on First Names, and built a list of about 6,000 names from public census data.  I also built a new list of nearly 38,000 Adjectives.

The combination actually works pretty well! While smelly-Susan isn't particularly charming, it's certainly not an ad hominem attack targeted at any particular Susan! That 6,000 x 38,000 gives us well over 228 million unique combinations!

Moreover, I also thought about how I could actually make it infinitely extensible... The simple rules of English allow Adjectives to modify Nouns, while Adverbs can recursively modify other Adverbs or Adjectives.   How convenient!

So I built a word list of Adverbs (13,000) as well, and added support for specifying the "number" of words in a PetName.
  1. If you want 1, you get a random Name
  2. If you want 2, you get a random Adjective followed by a Name
  3. If you want 3 or more, you get N-2 Adverbs, an Adjective and a Name
Oh, and the separator is now optional, and can be any character or string, with a default of a hyphen, "-".

In fact:
  • 2 words will generate over 221 million unique combinations, over 227 combinations
  • 3 words will generate over 2.8 trillion unique combinations, over 241 combinations (more than 32-bit space)
  • 4 words can generate over 255 combinations
  • 5 words can generate over 268 combinations (more than 64-bit space)
Interestingly, you need 10 words to cover 128-bit space!  So it's

unstoutly-clashingly-assentingly-overimpressibly-nonpermissibly-unfluently-chimerically-frolicly-irrational-wonda

versus

b9643037-4a79-412c-b7fc-80baa7233a31

Shell

So once the algorithm was spec'd out, I built and packaged a simple shell utility and text word lists, called petname, which are published at:
The packages are already in Ubuntu 15.04 (Vivid). On any other version of Ubuntu, you can use the PPA:

$ sudo apt-add-repository ppa:petname/ppa
$ sudo apt-get update

And:
$ sudo apt-get install petname
$ petname
itchy-Marvin
$ petname -w 3
listlessly-easygoing-Radia
$ petname -s ":" -w 5
onwardly:unflinchingly:debonairly:vibrant:Chandler

Python

That's only really useful from the command line, though. In MAAS, we'd want this in a native Python library. So it was really easy to create python-petname, source now published at:
The packages are already in Ubuntu 15.04 (Vivid). On any other version of Ubuntu, you can use the PPA:

$ sudo apt-add-repository ppa:python-petname/ppa
$ sudo apt-get update

And:
$ sudo apt-get install python-petname
$ python-petname
flaky-Megan
$ python-petname -w 4
mercifully-grimly-fruitful-Salma
$ python-petname -s "" -w 2
filthyLaurel

Using it in your own Python code looks as simple as this:

$ python
⟫⟫⟫ import petname
⟫⟫⟫ foo = petname.Generate(3, "_")
⟫⟫⟫ print(foo)
boomingly_tangible_Mikayla

Golang


In the way that NamesGenerator is useful to Docker, I though a Golang library might be useful for us in LXD (and perhaps even usable by Docker or others too), so I created:
Of course you can use "go get" to fetch the Golang package:

$ export GOPATH=$HOME/go
$ mkdir -p $GOPATH
$ export PATH=$PATH:$GOPATH/bin
$ go get github.com/dustinkirkland/golang-petname

And also, the packages are already in Ubuntu 15.04 (Vivid). On any other version of Ubuntu, you can use the PPA:

$ sudo apt-add-repository ppa:golang-petname/ppa
$ sudo apt-get update

And:
$ sudo apt-get install golang-petname
$ golang-petname
quarrelsome-Cullen
$ golang-petname -words=1
Vivian
$ golang-petname -separator="|" -words=10
snobbily|oracularly|contemptuously|discordantly|lachrymosely|afterwards|coquettishly|politely|elaborate|Samir

Using it in your own Golang code looks as simple as this:

package main
import (
"fmt"
"math/rand"
"time"
"github.com/dustinkirkland/golang-petname"
)
func main() {
flag.Parse()
rand.Seed(time.Now().UnixNano())
fmt.Println(petname.Generate(2, ""))
}
Gratuitous picture of my pets, 7 years later.
Cheers,
happily-hacking-Dustin

Read more
Dustin Kirkland


As promised last week, we're now proud to introduce Ubuntu Snappy images on another of our public cloud partners -- Google Compute Engine.
In the video below, you can join us walking through the instructions we have published here.
Snap it up!
:-Dustin

Read more
Dustin Kirkland



A couple of months ago, I re-introduced an old friend -- Ubuntu JeOS (Just enough OS) -- the smallest, (merely 63MB compressed!) functional OS image that we can still call “Ubuntu”.  In fact, we call it Ubuntu Core.

That post was a prelude to something we’ve been actively developing at Canonical for most of 2014 -- Snappy Ubuntu Core!  Snappy Ubuntu combines the best of the ground-breaking image-based Ubuntu remix known as Ubuntu Touch for phones and tablets with the base Ubuntu server operating system trusted by millions of instances in the cloud.

Snappy introduces transactional updates and atomic, image based workflows -- old ideas implemented in databases for decades -- adapted to Ubuntu cloud and server ecosystems for the emerging cloud design patterns known as microservice architectures.

The underlying, base operating system is a very lean Ubuntu Core installation, running on a read-only system partition, much like your iOS, Android, or Ubuntu phone.  One or more “frameworks” can be installed through the snappy command, which is an adaptation of the click packaging system we developed for the Ubuntu Phone.  Perhaps the best sample framework is Docker.  Applications are also packaged and installed using snappy, but apps run within frameworks.  This means that any of the thousands of Docker images available in DockerHub are trivially installable as snap packages, running on the Docker framework in Snappy Ubuntu.

Take Snappy for a Drive


You can try Snappy for yourself in minutes!

You can download Snappy and launch it in a local virtual machine like this:

$ wget http://cdimage.ubuntu.com/ubuntu-core/preview/ubuntu-core-alpha-01.img
$ kvm -m 512 -redir :2222::22 -redir :4443::443 ubuntu-core-alpha-01.img

Then, SSH into it with password 'ubuntu':

$ ssh -p 2222 ubuntu@localhost

At this point, you might want to poke around the system.  Take a look at the mount points, and perhaps try to touch or modify some files.


$ sudo rm /sbin/init
rm: cannot remove ‘/sbin/init’: Permission denied
$ sudo touch /foo

touch: cannot touch ‘foo’: Permission denied
$ apt-get install docker
apt-get: command not found

Rather, let's have a look at the new snappy package manager:

$ sudo snappy --help



And now, let’s install the Docker framework:

$ sudo snappy install docker

At this point, we can do essentially anything available in the Docker ecosystem!

Now, we’ve created some sample Snappy apps using existing Docker containers.  For one example, let’s now install OwnCloud:

$ sudo snappy install owncloud

This will take a little while to install, but eventually, you can point a browser at your own private OwnCloud image, running within a Docker container, on your brand new Ubuntu Snappy system.

We can also update the entire system with a simple command and a reboot:
$ sudo snappy versions
$ sudo snappy update
$ sudo reboot

And we can rollback to the previous version!
$ sudo snappy rollback
$ sudo reboot

Here's a short screencast of all of the above...


While the downloadable image is available for your local testing today, you will very soon be able to launch Snappy Ubuntu instances in your favorite public (Azure, GCE, AWS) and private clouds (OpenStack).


Enjoy!
Dustin

Read more
pitti

I’m on my way home from Düsseldorf where I attended the LinuxCon Europe and Linux Plumber conferences. I was quite surprised how huge LinuxCon was, there were about 1.500 people there! Certainly much more than last year in New Orleans.

Containers (in both LXC and docker flavors) are the Big Thing everybody talks about and works with these days; there was hardly a presentation where these weren’t mentioned at all, and (what felt like) half of the presentations were either how to improve these, or how to use these technologies to solve problems. For example, some people/companies really take LXC to the max and try to do everything in them including tasks which in the past you had only considered full VMs for, like untrusted third-party tenants. For example there was an interesting talk how to secure networking for containers, and pretty much everyone uses docker or LXC now to deploy workloads, run CI tests. There are projects like “fleet” which manage systemd jobs across an entire cluster of containers (distributed task scheduler) or like project-builder.org which auto-build packages from each commit of projects.

Another common topic is the trend towards building/shipping complete (r/o) system images, atomic updates and all that goodness. The central thing here was certainly “Stateless systems, factory reset, and golden images” which analyzed the common requirements and proposed how to implement this with various package systems and scenarios. In my opinion this is certainly the way to go, as our current solution on Ubuntu Touch (i. e. Ubuntu’s system-image) is far too limited and static yet, it doesn’t extend to desktops/servers/cloud workloads at all. It’s also a lot of work to implement this properly, so it’s certainly understandable that we took that shortcut for prototyping and the relatively limited Touch phone environment.

On Plumbers my main occupations were mostly the highly interesting LXC track to see what’s coming in the container world, and the systemd hackfest. On the latter I was again mostly listening (after all, I’m still learning most of the internals there..) and was able to work on some cleanups and improvements like getting rid of some of Debian’s patches and properly run the test suite. It was also great to sync up again with David Zeuthen about the future of udisks and some particular proposed new features. Looks like I’m the de-facto maintainer now, so I’ll need to spend some time soon to review/include/clean up some much requested little features and some fixes.

All in all a great week to meet some fellows of the FOSS world a gain, getting to know a lot of new interesting people and projects, and re-learning to drink beer in the evening (I hardly drink any at home :-P).

If you are interested you can also see my raw notes, but beware that there are mostly just scribbling.

Now, off to next week’s Canonical meeting in Washington, DC!

Read more
Dustin Kirkland


Docker 1.0.1 is available for testing, in Ubuntu 14.04 LTS!

Docker 1.0.1 has landed in the trusty-proposed archive, which we hope to SRU to trusty-updates very soon.  We would love to have your testing feedback, to ensure both upgrades from Docker 0.9.1, as well as new installs of Docker 1.0.1 behave well, and are of the highest quality you have come to expect from Ubuntu's LTS  (Long Term Stable) releases!  Please file any bugs or issues here.

Moreover, this new version of the Docker package now installs the Docker binary to /usr/bin/docker, rather than /usr/bin/docker.io in previous versions. This should help Ubuntu's Docker package more closely match the wealth of documentation and examples available from our friends upstream.

A big thanks to Paul Tagliamonte, James Page, Nick Stinemates, Tianon Gravi, and Ryan Harper for their help upstream in Debian and in Ubuntu to get this package updated in Trusty!  Also, it's probably worth mentioning that we're targeting Docker 1.1.2 (or perhaps 1.2.0) for Ubuntu 14.10 (Utopic), which will release on October 23, 2014.

Here are a few commands that might help your testing...

Check What Candidate Versions are Available

$ sudo apt-get update
$ apt-cache show docker.io | grep ^Version:

If that shows 0.9.1~dfsg1-2 (as it should), then you need to enable the trusty-proposed pocket.

$ echo "deb http://archive.ubuntu.com/ubuntu/ trusty-proposed universe" | sudo tee -a /etc/apt/sources.list
$ sudo apt-get update
$ apt-cache show docker.io | grep ^Version:

And now you should see the new version, 1.0.1~dfsg1-0ubuntu1~ubuntu0.14.04.1, available (probably in addition to 1.0.1~dfsg1-0ubuntu1~ubuntu0.14.04.1).

Upgrades

Check if you already have Docker installed, using:

$ dpkg -l docker.io

If so, you can simply upgrade.

$ sudo apt-get upgrade

And now, you can check your Docker version:

$ sudo dpkg -l docker.io | grep -m1 ^ii | awk '{print $3}'
0.9.1~dfsg1-2

New Installations

You can simply install the new package with:

$ sudo apt-get install docker.io

And ensure that you're on the latest version with:

$ dpkg -l docker.io | grep -m1 ^ii | awk '{print $3}'
1.0.1~dfsg1-0ubuntu1~ubuntu0.14.04.1

Running Docker

If you're already a Docker user, you probably don't need these instructions.  But in case you're reading this, and trying Docker for the first time, here's the briefest of quick start guides :-)

$ sudo docker pull ubuntu
$ sudo docker run -i -t ubuntu /bin/bash

And now you're running a bash shell inside of an Ubuntu Docker container.  And only bash!

root@1728ffd1d47b:/# ps -ef
UID PID PPID C STIME TTY TIME CMD
root 1 0 0 13:42 ? 00:00:00 /bin/bash
root 8 1 0 13:43 ? 00:00:00 ps -ef

If you want to do something more interesting in Docker, well, that's whole other post ;-)

:-Dustin

Read more
