Posts tagged with 'arm'

Dustin Kirkland

I happen to have a full mirror of the entire Ubuntu Xenial archive here on a local SSD, and I took the opportunity to run a few numbers...
  • 6: This is our 6th Ubuntu LTS
    • 6.06, 8.04, 10.04, 12.04, 14.04, 16.04
  • 7: With Ubuntu 16.04 LTS, we're supporting 7 CPU architectures
    • armhf, arm64, i386, amd64, powerpc, ppc64el, s390x
  • 25,671: Ubuntu 16.04 LTS is comprised of 25,671 source packages
    • main, universe, restricted, multiverse
  • 150,562+: Over 150,562 (and counting!) cloud instances of Xenial have launched to date
    • and we haven't even officially released yet!
  • 216,475: A complete archive of all binary .deb packages in Ubuntu 16.04 LTS consists of 216,475 debs.
    • 24,803 arch independent
    • 27,159 armhf
    • 26,845 arm64
    • 28,730 i386
    • 28,902 amd64
    • 27,061 powerpc
    • 26,837 ppc64el
    • 26,138 s390x
  • 1,426,792,926: A total line count of all source packages in Ubuntu 16.04 LTS using cloc yields 1,426,792,926 total lines of source code
  • 250,478,341,568: A complete archive all debs, all architectures in Ubuntu 16.04 LTS requires 250GB of disk space
Yes, that's 1.4 billion lines of source code comprising the entire Ubuntu 16.04 LTS archive.  What an amazing achievement of open source development!

Perhaps my fellow nerds here might be interested in a breakdown of all 1.4 billion lines across 25K source packages, and throughout 176 different programming languages, as measured by Al Danial's cloc utility.  Interesting data!

You can see the full list here.  What further insight can you glean?


Read more
Dustin Kirkland

Forget about The Year of the Linux Desktop...This is The Year of the Linux Countertop!

I'm talking about Linux on every form of Internet-connected embedded devices.  The Internet-of-Things is already upon us.  Sensors, smart watches, TVs, thermostats, security cameras, drones, printers, routers, switches, robots -- you name it.

And with that backdrop, we are thrilled to introduce Snappy Ubuntu for Devices.  Ubuntu is now a possibility, on almost any device, anywhere.  Now that's exciting!

This is the same Snappy Ubuntu, with its atomic, transactional updates that we launched on each major public cloud last month -- extended and updated for 64-bit Intel, AMD and ARM devices.

Now, if you want a detailed, developer's look at building a Snappy Ubuntu image and running it on a BeagleBone, you're in luck!  I shot this little instructional video (using Cheese, GTK-RecordMyDesktop, and OpenShot).  Enjoy!

A transcript of the video follows...

  1. What is Snappy Ubuntu?
    • A few weeks ago, we introduced a new flavor of Ubuntu that we call “Snappy” -- an atomically, transactionally updated Operating System -- and showed how to launch, update, rollback, and install apps in cloud instances of Snappy Ubuntu in Amazon EC2, Microsoft Azure, and Google Compute Engine public clouds.
    • And now we’re showing how that same Snappy Ubuntu experience is the perfect operating system for today’s Cambrian Explosion of smart devices that some people are calling “the Internet of Things”!
    • Snappy Ubuntu Core bundles only the essentials of a modern, appstore powered Linux OS stack and hence leaves room both in size as well as flexibility to build, maintain and monetize very own device solution without having to care about the overhead of inventing and maintaining your own OS and tools from scratch. Snappy Ubuntu Core comes right in time for you to put your very own stake into stake into still unconquered worlds of things
    • We think you’ll love Snappy on your smart devices for many of the same reasons that there are already millions of Ubuntu machine instances in hundreds of public and private clouds, as well as the millions of your own Ubuntu desktops, tablets, and phones!
  2. Unboxing the BeagleBone
    • Our target hardware for this Snappy Ubuntu demo is the BeagleBone Black -- an inexpensive, open platform for hardware and software developers.
    • I paid $55 for the board, and $8 for a USB to TTL Serial Cable
    • The board is about the size of a credit card, has a 1GHz ARM Cortex A8 processor, 512MB RAM, and on board ethernet.
    • While Snappy Ubuntu will run on most any armhf or amd64 hardware (including the Intel NUC), the BeagleBone is perhaps the most developer friendly solution.
  3. The easiest way to get your Snappy Ubuntu running on your Beaglebone
    • The world of Devices has so many opportunities that it won’t be possible to give everyone the perfect vertical stack centrally. Hence Canonical is trying to enable all of you and provide you with the elements that get you started doing your innovation as quickly as possible. Since there will be many devices that won’t need a screen and input devices, we have developed “webdm”. webdm gives you the ability to manage your snappy device and consume apps without any development effort.
    • To installl you simply download our prebuilt WEB .img and dd it to your sd card.
    • After that all you ahve to do is to connect your beaglebone to a DHCP enabled local network and power it on.
    • After 1-2 minutes you go to http://webdm.local:8080 and can get onto installing apps from the snappy appstore without any further effort
    • Of course, we are still in beta and will continue give you more features and a greater experience over time; we will not only make the UI better, but also work on various customization options that allow you to deliver your own app store powered product without investing your development resources in something that already got solved.
  4. Downloading Snappy and writing to an sdcard
    • Now we’re going to build a Snappy Ubuntu image to run on our device.
    • Soon, we’ll publish a library of Snappy Ubuntu images for many popular devices, but for this demo, we’re going to roll our own using the tool, ubuntu-device-flash.
    • ls -halF mysnappy.img
    • sudo dd if=mysnappy.img of=/dev/mmblk0 bs=1M oflag=dsync
  5. Hooking up the BeagleBone
    • Insert the microsd card
    • Network cable
    • USB debug
    • Power/USB
  6. Booting Snappy and command line experience
    • Okay, so we’re ready for our first boot of Snappy!
    • Let’s attach to the USB/serial console using screen
    • Now, I’ll attach the power, and if you watch very carefully, you might get to see some a few boot messages.
    • snappy help
    • ifconfig
    • ssh ubuntu@
  7. WebDM experience
    • snappy info
    • Shows we have the webdm framework installed
    • point browser to
    • Configuration
    • Store
  8. Conclusion
    • Hey how cool is that!  Snappy Ubuntu running on devices :-)
    • I’ve spent plenty of time and money geeking out over my Nest and Dropcam and Netatmo and WeMo lightswitches, playing with their APIs and hooking them up to If-This-Then-That.
    • But I’m really excited about a world where those types of devices are as accessible to me as my Ubuntu servers and desktops!
    • And from what I’ve shown you here, with THIS, I think we can safely say that that we’ve blown right past the year of the Linux desktop.
    • This is the year of the Linux countertop!


Read more

In the ubuntu download manager we are using the new connection style syntax so that if there are errors in the signal connections we will be notified at compile time. However, in recent versions of udm we have noticed that the udm tests that ensure that the qt signals are emitted correctly have started failing randomly in the build servers.

As it can be seen in the following build logs the compilation does finish with no errors but the tests raise errors at runtime (an assert was added for each of the connect calls in the project):

Some of the errors between the diff archs are the same but this feels like a coincidence. The unity-scope-click package project has had the same issue and has solved it in the following way:

    // NOTE: using SIGNAL/SLOT macros here because new-style
    // connections are flaky on ARM.
    c = connect(impl->, SIGNAL(downloadCreated(Download*)),
                this, SLOT(handleDownloadCreated(Download*)));
    if (!c) {
        qDebug() << "failed to connect to systemDownloadManager::downloadCreated";

I am not the only one that have encoutered this bug within canonical (check out this bug). Apprently -Bsymbolic breaks PMF (Pointer to Member Function) comparison under ARM as it was reported in linaro. As it is explained in the Linaro mailing list a workaround to this (since the correct way would be to fix the linker) is to build with PIE support. The Qt guys have decided to drop -Bsymbolic* on anything but x86 and x86-64. I hope all this info help others that might find the same problem.

Read more
Federico Lucifredi

Today we’re introducing some new features into Ubuntu’s systems management and monitoring tool, Landscape. Organisations will now be able to use Landscape to manage Hyperscale environments ranging from ARM to x86 low-power designs, adding to Landscape’s existing coverage of Ubuntu in the cloud, data centre server, and desktop environments. There’s an update to the Dedicated Server too, bringing SAAS and Dedicated Server versions in alignment.

Calxeda 'Serial Number 0' in Canonical's lab

Hyperscale is set to address today’s infrastructure challenges by providing compute capacity with less power for lower cost. Canonical is at the forefront of the trend. Ubuntu already powers scale-out workloads on a new wave of low-cost ultradense hardware based on x86 and ARM processors including Calxeda EnergyCore and Intel Atom designs. Ubuntu is also the default OS for HP’s Project Moonshot servers.

Calxeda 01 - Wide

This update includes support for ARM processors and allows organisations to manage thousands of Hyperscale machines as easily as one, making it more cost-effective to run growing networks spanning tens of thousands of devices. The same patch management and compliance features are available for ARM as they are for x86 environments, making Landscape the first systems management tool of a leading Linux vendor to introduce ARM support – and we are doing so on a level of feature parity across architectures.

Calxeda is the leading innovator engaged in bringing ARM chips to servers and partnered with us early on to bring Ubuntu to their new platform. “Landscape system management support for ARM is a huge step forward”, said Larry Wikelius, co-founder and Vice President at Calxeda. “Adding datacenter-class management to the Ubuntu platform for ARM demonstrates Canonical’s commitment to innovation for Hyperscale customers, who are looking to Calxeda to help improve their power efficiency.”

Calxeda 'Serial number 0' in Canonical's Boston lab

“Landscape’s support for the ARM architecture extends to all ARM SoCs supported by Ubuntu, but we adopted the Calxeda EnergyCore systems in our labs as the reference design in light of both their early arrival to market and their maturity”, said Federico Lucifredi, Product Manager for Landscape and Ubuntu Server at Canonical, adding “we are excited to be bringing Landscape to Hyperscale systems on both ARM and x86 Atom architectures.” CIOs and System Administrators considering implementing Hyperscale environments on Ubuntu will now have access to the same enterprise-grade systems management and monitoring capabilities they enjoy in their data centres today with Landscape.

Kurt Keville, HPC Researcher at Massachusetts Institute of Technology (MIT) commented: “MIT’s interest in low power computing designs aims to achieve the execution of production HPC codes at the same level of numerical performance, yet within a smaller power envelope.”  He added: “With Landscape, we can manage our ARM development clusters with the same kind of granularity we are accustomed to on x86 systems. We are able to manage ARM compute clusters without affecting our production network bandwidth in any way”.

Parallella Gen0 prototypes stack

The Parallella Board project aims to make parallel computing ubiquitous through an affordable Open Hardware platform equipped with Open Source tools. Andreas Olofsson, CEO, Adapteva said: “We selected Ubuntu as our default platform because of its popularity with the developer Community and relentless pace of updating, regularly providing our users with the newest builds for any project.”  He added: “ The availability of a management and monitoring platform like Landscape is essential to managing complexity as the scale of Parallella clusters rapidly reaches into the hundreds or even thousands of nodes.”

Parallella 01 - Processes

As we talk to customers building cloud infrastructure or big data computing environments, it’s clear that power consumption and efficient scaling are key drivers to their architectural decisions. When these considerations are coupled with Landscape’s efficiency and scalable management characteristics, we believe enterprises will be able to achieve a significant shift in both scalability and manageability in their data centre through Hyperscale architecture.

Ubuntu is the default OS for HP’s project Moonshot cartridges, ships or is available for download to every Moonshot customer, with direct support from HP backed by Canonical’s worldwide support organization.  The Landscape update today also means that the full bundle of Ubuntu Advantage support and services becomes available to Moonshot customers.

“Canonical continues to lead the way in the Hyperscale OS arena introducing full enterprise-grade support services for Ubuntu on Hyperscale hardware”, remarked Martin Stadtler, Director of Support Services at Canonical.

Landscape’s Dedicated Server edition has also been refreshed in this update. This means that those businesses choosing to keep the service onsite (rather than hosted) will benefit from the same functionality and a series of updates already available to SAAS customers, including the new audit log facility and performance enhancements, while retaining full local control of their management infrastructure.

Read more

Samsung announced an 8 core! yes an 8 core ARM processor which may power the Samsung Galaxy S4

Rather than a single eight-core chip, it has two quad-cores inside – one being a quad-core ARM Cortex A15 and the other a quad-core Cortex A7. The Cortex A15 deals with the tough stuff but passes off the easy tasks to the Cortex A7, or they can both be fired up to really show off. This means it’s strong enough to provide all the power you may need, while at the same time being smart enough to conserve energy when it can. If you’re wondering just how much difference the Exynos 5 Octa and other big.LITTLE chips will make when used in a device, ARM’s CEO Warren East said he expects “twice the performance and half the power consumption” compared to today’s best offerings.

Read More.

Read more

While ARM is gaining a lot of momentum, the challenge with ARM until now was that every architecture is very different from different vendors and requires a separate kernel and entire OS stack.

With Linux Kernel 3.7, this has changed for the better.

ARM’s problem was that, unlike the x86 architecture, where one Linux kernel could run on almost any PC or server, almost every ARM system required its own customized Linux kernel. Now with 3.7, ARM architectures can use one single vanilla Linux kernel while keeping their special device sauce in device trees.

The end result is that ARM developers will be able to boot and run Linux on their devices and then worry about getting all the extras to work. This will save them, and the Linux kernel developers, a great deal of time and trouble.

Just as good for those ARM architects and programmers who are working on high-end, 64-bit ARM systems, Linux now supports 64-bit ARM processors. 64-bit ARM CPUs won’t ship until in commercial quantities until 2013. When they do arrive though programmers eager to try 64-bit ARM processors on servers will have Linux ready for them.

Read More.

Read more

I just released Apport 2.7.

The main new feature is supporting foreign architectures in apport-retrace. If apport-retrace works in sandbox mode and works on a crash that was not produced on the same architecture as apport-retrace is running on, it will now build a sandbox for the report’s architecture and invoke gdb with the necessary magic options to produce a proper stack trace (and the other gdb information).
Right now this works for i386, x86_64, and ARMv7, but if someone is interested in making this work for other architectures, please ping me.

This is rolled out to the Launchpad retracers, see for example Bug #1088428. So from now on you can report your armhf crashes to Launchpad and they ought to be processed. Note that I did a mass-cleanup of old armhf crash bugs this morning, as the existing ones were way too old to be retraced.

For those who are running their own retracers for their project: You need to add an armhf specific apt sources list your per-release configuration directory, e. g. Ubuntu 12.04/armhf/sources.list as armhf is on instead of Also, you need to add an armhf crash database to your crashdb.conf and add a cron job for the new architecture. You can see how all this looks like in the configuration files for the Launchpad retracers.

The other improvement concerns package hooks. So far, when a package hook crashed the exception was only printed to stderr, where most people would never see them when using the GTK or KDE frontend. With 2.7 these exceptions are also added to the report itself (HookError_filename), so that they appear in the bug reports.

The release also fixes a couple of bugs, see the release notes for details.

Read more

The Ubuntu Developer Summit was held in Copenhagen last week, to discuss plans for the next six-month cycle of Ubuntu. This was the most productive UDS that I've been to — maybe it was the shorter four-day schedule, or the overlap with Linaro Connect, but it sure felt like a whirlwind of activity.

I thought I'd share some details about some of the sessions that cover areas I'm working on at the moment. In no particular order:

Improving cross-compilation

Blueprint: foundations-r-improve-cross-compilation

This plan is a part of a mutli-cycle effort to improve cross-compilation support in Ubuntu. Progress is generally going well — the consensus from the session was that the components are fairly close to complete, but we still need some work to pull those parts together into something usable.

So, this cycle we'll be working on getting that done. While we have a few bugfixes and infrastructure updates to do, one significant part of this cycle’s work will be to document the “best-practices” for cross builds in Ubuntu, on This process will be heavily based on existing pages on the Linaro wiki. Because most of the support for cross-building is already done, the actual process for cross-building should be fairly straightforward, but needs to be defined somewhere.

I'll post an update when we have a working draft on the Ubuntu wiki, stay tuned for details.

Rapid archive bringup for new hardware

Blueprint: foundations-r-rapid-archive-bringup

I'd really like for there to be a way to get an Ubuntu archive built “from scratch”, to enable custom toolchain/libc/other system components to be built and tested. This is typically useful when bringing up new hardware, or testing rebuilds with new compiler settings. Because we may be dealing with new hardware, doing this bootstrap through cross-compilation is something we'd like too.

Eventually, it would be great to have something as straightforward as the OpenEmbedded or OpenWRT build process to construct a repository with a core set of Ubuntu packages (say, minbase), for previously-unsupported hardware.

The archive bootstrap process isn't done often, and can require a large amount of manual intervention. At present, there's only a couple of folks who know how to get it working. The plan here is to document the bootstrap process in this cycle, so that others can replicate the process, and possibly improve the bits that are a little too janky for general consumption.

ARM64 / ARMv8 / aarch64 support

Blueprint: foundations-r-aarch64

This session is an update for progress on the support for ARMv8 processors in Ubuntu. While no general-purpose hardware exists at the moment, we want to have all the pieces ready for when we start seeing initial implementations. Because we don't have hardware yet, this work has to be done in a cross-build environment; another reason to keep on with the foundations-r-improve-cross-compilation plan!

So far, toolchain progress is going well, with initial cross toolchains available for quantal.

Although kernel support isn’t urgent at the moment, we’ll be building an initial kernel-headers package for aarch64. There's also a plan to get a page listing the aarch64-cross build status of core packages, so we'll know what is blocked for 64-bit ARM enablement.

We’ve also got a bunch of workitems for volunteers to fix cross-build issues as they arise. If you're interested, add a workitem in the blueprint, and keep an eye on it for updates.

Secure boot support in Ubuntu

Blueprint: foundations-r-secure-boot

This session covered progress of secure boot support as at the 12.10 Quantal Quetzal release, items that are planned for 13.04, and backports for 12.04.2.

As for 12.10, we’ve got the significant components of secure boot support into the release — the signed boot chain. The one part that hasn't hit 12.10 yet is the certificate management & update infrastructure, but that is planned to reach 12.10 by way of a not-too-distant-future update.

The foundations team also mentioned that they were starting the 12.04.2 backport right after UDS, which will bring secure boot support to our current “Long Term Support” (LTS) release. Since the LTS release is often preferred Ubuntu preinstall situations, this may be used as a base for hardware enablement on secure boot machines. Combined with the certificate management tools (described at sbkeysync & maintaining uefi key databases), and the requirement for “custom mode” in general-purpose hardware, this will allow for user-defined trust configuration in an LTS release.

As for 13.04, we're planning to update the shim package to a more recent version, which will have Matthew Garrett's work on the Machine Owner Key plan from SuSE.

We're also planning to figure out support for signed kernel modules, for users who wish to verify all kernel-level code. Of course, this will mean some changes to things like DKMS, which run custom module builds outside of the normal Ubuntu packages.

Netboot with secure boot is still in progress, and will require some fixes to GRUB2.

And finally, the sbsigntools codebase could do with some new testcases, particularly for the PE/COFF parsing code. If you're interested in contributing, please contact me at

Read more

Cross-compile-o-naut wookey has recently posted a set of Debian & Ubuntu packages for an aarch64 (ie, 64-bit ARMv8) cross compiler:

The repositories here contain sources and binaries for the arm64 bootstrap in Debian (unstable) and Ubuntu (quantal). There are both toolchain and tools packages for amd64 build machines and arm64 binaries built with them. And corresponding sources.

For the lazy:

[jk@pecola ~]$ wget -O - |
    sudo apt-key add -
[jk@pecola ~]$ sudo apt-add-repository 'deb quantal-bootstrap main universe'
[jk@pecola ~]$ sudo apt-get update
[jk@pecola ~]$ sudo apt-get install --install-recommends gcc-4.7-aarch64-linux-gnu

... which gives you a cross compiler for aarch64:

[jk@pecola ~]$ cat helloworld.c
#include <stdio.h>
int main(void) { printf("hello world\n"); return 0; }
[jk@pecola ~]$ aarch64-linux-gnu-gcc-4.7 -Wall -O2 -o helloworld helloworld.c
[jk@pecola ~]$ aarch64-linux-gnu-objdump -f helloworld
helloworld:     file format elf64-littleaarch64
architecture: aarch64, flags 0x00000112:
start address 0x0000000000400450

Read more

Most of the components of the 64-bit ARM toolchain have been released, so I've put together some details on building a cross compiler for aarch64. At present, this is only binutils & compiler (ie, no libc), so is probably not useful for applications. However, I have a 64-bit ARM kernel building without any trouble.

Update: looking for an easy way to install a cross-compiler on Ubuntu or debian? Check out aarch64 cross compiler packages for Ubuntu & Debian.

pre-built toolchain

If you're simply looking to download a cross compiler, here's one I've built earlier: aarch64-cross.tar.gz (.tar.gz, 85MB). It's built for an x86_64 build machine, using Ubuntu 12.04 LTS, but should work with other distributions too.

The toolchain is configured for paths in /opt/cross/. To install it, do a:

[jk@pecola ~]$ sudo mkdir /opt/cross
[jk@pecola ~]$ sudo chown $USER /opt/cross
[jk@pecola ~]$ tar -C /opt/cross/ -xf aarch64-x86_64-cross.tar.gz

If you'd like to build your own, here's how:

initial setup

We're going to be building in ~/build/aarch64-toolchain/, and installing into /opt/cross/aarch64/. If you'd prefer to use other paths, simply change these in the commands below.

[jk@pecola ~]$ mkdir -p ~/build/arm64-toolchain/
[jk@pecola ~]$ cd ~/build/arm64-toolchain/
[jk@pecola ~]$ prefix=/opt/cross/aarch64/

We'll also need a few packages for the build:

[jk@pecola ~]$ sudo apt-get install bison flex libmpfr-dev libmpc-dev texinfo


I have a git repository with a recent version of ARM's aarch64 support, plus a few minor updates at git:// (or browse the gitweb view). To build:

Update: arm64 support has been merged into upstream binutils, so you can now use the official git repository. The commit 02b16151 builds successfully for me.

[jk@pecola arm64-toolchain]$ git clone git://
[jk@pecola arm64-toolchain]$ cd binutils
[jk@pecola binutils]$ ./configure --prefix=$prefix --target=aarch64-none-linux
[jk@pecola binutils]$ make
[jk@pecola binutils]$ make install
[jk@pecola binutils]$ cd ..

kernel headers

Next up, the kernel headers. I'm using Catalin Marinas' kernel tree on here. We don't need to do a full build (we don't have a compiler yet..), just the headers_install target.

[jk@pecola arm64-toolchain]$ git clone git://
[jk@pecola arm64-toolchain]$ cd linux-aarch64
[jk@pecola linux-aarch64]$ git reset --hard b6fe1645
[jk@pecola linux-aarch64]$ make ARCH=arm64 INSTALL_HDR_PATH=$prefix headers_install
[jk@pecola linux-aarch64]$ cd ..


And now we should have things ready for the compiler build. I have a git tree up at git:// (gitweb), but this is just the aarch64 branch of upstream gcc.

[jk@pecola arm64-toolchain]$ git clone git://
[jk@pecola arm64-toolchain]$ cd gcc/aarch64-branch/
[jk@pecola aarch64-branch]$ git reset --hard d6a1e14b
[jk@pecola aarch64-branch]$ ./configure --prefix=$prefix \
    --target=aarch64-none-linux --enable-languages=c \
    --disable-threads --disable-shared --disable-libmudflap \
    --disable-libssp --disable-libgomp --disable-libquadmath
[jk@pecola aarch64-branch]$ make
[jk@pecola aarch64-branch]$ make install
[jk@pecola aarch64-branch]$ cd ../..

That's it! You should have a working compiler for arm64 kernels in /opt/cross/aarch64.

Read more

This week I’m proudly participating at the Ubuntu Developer Summit to help planning and defining what will the Quantal Quetzal (12.10) release be in the next following months.

As usual I’m wearing not only the Linaro hat, but also my Ubuntu and Canonical ones, interested and participating actively at most topics that are related with ARM in general.

And what can I say after the first 3 days at UDS-Q? Well, busy as never before and with great opportunities to help getting Ubuntu to rock even more at ARM, with current devices/platforms and with the exciting new ones that will be coming in the next few months.

Here are a few highlights from the first days:

Monday – May 7th

  • Introduction and Keynote
    • Great start as usual by Mark, showing the great opportunities for both Canonical and Ubuntu, describing the new target and use cases, and also showing how important Cloud is now for Ubuntu. After that we had, finally, the announcement of a real hardware availability from Calxeda, proving that ARM server are indeed real! (which is a quite important accomplishment)
  • Schedule displays all working with our member’s boards
    • This was the first time that all the schedule displays available at UDS were all covered by the ARM boards provided by Linaro. This time we got Pandaboard, Origen and also Snowball constantly showing the schedule through all the day. Low power and powerful devices all around :-)
  • Plans for a minimum filesystem for embedded devices
    • Discussion to cover all the possible embedded related use cases for Ubuntu, and trying to understand the real requirements for a minimum filesystem (rootfs) for those devices. While we didn’t decide to generate the smallest-still-apt/dpkg-compatible rootfs for our users (as ubuntu-core is already covering most of the cases), we’ll provide enough tools and documentation on how to easily generate them. At Linaro side the Ubuntu Nano image should probably reflect such suggestions.
  • Identify impact of the switch to pure live images for ARM platforms
    • Here the focus was basically to review and understand if we would really continue providing pre-installed based images instead of just supporting live based ones. Having the images provided only at the SD cards are very useful to make the bootstrap and install quite easy, but it hurts badly the performance. As we’re now getting ARM boards that are very powerful in many ways, the I/O bound shouldn’t limit what the users would be able to get from them. The decision for Quantal is to drop support for the pre-installed images, and provide live based ones at the SD cards (think like the live-sd image as we have with CD on other archs), where the user would install Ubuntu the same way as done with x86, and using USB/Sata based devices as rootfs by default.
  • OpenStack Deployment on ARM Server
    • The focus of this session was basically to better understand what might be the missing pieces for a proper OpenStack support at ARM. Quite a few open questions still, but the missing pkgs enablement, LXC testing and support and KVM for a few platforms will help making sure the support is at least correctly in place. After initial support, continuous test and validation should happen to make sure the ARM platforms keeps well supported over the time (which will be better stressed and tested once MAAS/Juju is also supported properly at ARM).

Tuesday – May 8th

  • Detail and begin the arm64/aarch64 port in Ubuntu
    • Clearly the most important session of the day for ARM. Great discussion on how to prepare and start the ARMv8 port at Ubuntu and Debian, by starting with cross-build support with multiarch and later support with Fast Models and Qemu. A lot is still to be covered once ARM is able to publish the ARMv8 support for Toolchain and Kernel, and session will be reviewed again at Linaro Connect at the end of this month.
  • Ubuntu Kernel Delta Review
    • Usual review of the patches the Ubuntu Kernel team is maintaining at the Ubuntu Kernel tree. At Linaro this is important as we also enable the Ubuntu specific patch-set at the packages provided by the LEB, for proper kernel and user-space support. Luckily this time it seems the delta is really minimum, which should probably also start to be part of Linux Linaro in the following month.
  • Integrate Linaro hwpacks for ARM with the Ubuntu image build infrastructure
    • Usual discussion about trying to avoid replicated work that is strictly related with each ARM board we support at both Ubuntu and Linaro. Decision is to finally sync with the latest flash-kernel available at Debian and try to get the common project/package with the hardware specific bits in place, so it can be used by linaro-image-tools, flash-kernel and debian-cd.

Wednesday – May 9th

  • MAAS Next Steps
    • Session to review and plan what are the next steps for the MAAS project, which is also missing proper ARM support for now. Great discussions on understanding all the requirements, as they will not necessarily match entirely with the usual ARM devices we have at the moment. Here the goal for ARM is to continue improving the PXE support at U-Boot (even with UEFI chainload later), and understanding what might be missing to also have IPMI support (even if not entirely provided by the hardware).
  • System Compositor
    • Great session covering what might be the improvements and development on the graphics side for next release. Goal is to use a system compositor that would be started right at the beginning at the boot, which will then be controlled and used properly once lightdm is up (with X11). This will improve a lot the user experience on normal x86 based desktops, and luckily on ARM we’re also in a quite nice situation with the work done by Linaro helping getting the proper DRM/KMS support for the boards we support, so I hope ARM will be in a great shape here :-)
  • ARM Server general enhancements (for ARMv7 and perhaps v8)
    • At this session we could cover what seems to be the most recurrent and problematically thing at supporting ARM servers, which is the lack of a single and supported boot method and boot loader. UEFI should be able to help on this front soon, but until then the focus will be to keep checking and making sure the current PXE implementation at u-boot works as expected (chainloading UEFI on u-boot is also another possibility Linaro is investigating). There is also the request for IPMI support, which is still unclear in general how it’ll be done generically speaking.
  • Integration testing for the bootloader
    • As Ubuntu is also moving to the direction of continuous validating and testing all important components available, there’s the need for a proper validation of the bootloader, and the effect at the user experience while booting the system. For ARM it’s also a special case, as U-Boot is still the main bootloader used across the boards. Test case descriptions in place, and discussion will probably continue at Linaro Connect as this is also an area where we also want to help validating/testing.
  • ARM Server Benchmarking and Performance
    • Here the Ubuntu Server Team presented how they are benchmarking and checking performance at the server level at x86, and covering what might still be needed to run and validate the ARM boards the same way. For ARM the plan is to run the same test cases on the available scenarios, and also try to get Linaro involved by making sure this is also part of the continuous validation and testing done with LAVA. Another important topic that will probably be extended at Linaro Connect is finding a way to get the power consumption data when running the test cases/benchmarks, so it can be further optimised later on.
  • Compiz GLES2 Handover
    • Last session of the day, trying to find the missing gaps to finally get the OpenGL ES2.0 support merged at the Compiz and Unity upstream branches used by the entire Ubuntu desktop (across all archs). Following work and actions will basically be to fix the remaining and important plugins after merging the changes, and also getting a few test cases to properly validate the support at Ubuntu. Once all done, it should be merged ASAP.

These are just a few topics which I was able to participate. There are a lot of more exciting work coming on, which can all be found at Remember that you’re still able to participate in a few of them tomorrow and friday, as remote access is provided for all the sessions we have.

I’m sure a lot of more exciting stuff will be discussed for ARM support until the end of this week, and at Linaro Connect, at the end of the month, we’ll be able to review and get our hands dirty as well :-)

Exciting times for ARM!

Read more
Mark Baker

On Monday, Calxeda, one of the leading innovators bringing revolutionary efficiency to the datacenter, unveiled their new EnergyCore reference server live onstage with Mark Shuttleworth at the Ubuntu Developer Summit (UDS) in Oakland California.


Calxeda CTO and Founder Larry Wikelius with Mark Shuttleworth at UDS

The choice of UDS at the venue to unveil the new hardware to the world was flattering and underlines how the innovators in next generation computing are building out a compelling platform together. Ubuntu and Calxeda have been working together for several years to bring Ubuntu on Calxeda to market in the form now being shown at UDS. The collaboration of Canonical and the Ubuntu community with Calxeda has been vital to be able to deliver a solution that can very easily deploy OpenStack based cloud using MAAS and Juju on hardware that is so innovative.

The EnergyCore reference server unveiled at UDS can house up to 48 Quadcore nodes at under 300 Watts with up to 24 SATA drives. In this configuration it is possible to house 1000 server instances in a single rack and other server form factors being developed by OEMs may enable several times this volume. It is precisely this type of power efficient technology that will accelerate the adoption of next generation hyperscale services such as cloud and we are proud to be at the very core of it.

So congratulations to Calxeda on the arrival of the EnergyCore and congratulations to Canonical and the Ubuntu Community for providing the platform that will power it.

Read more

For those following the development of the next Ubuntu release (12.04 – Precise Pangolin), you all know that we’re quite close to the release date already, and to make sure Precise rocks since day 0, we all need to work hard to get most of the bugs sorted out during the next few weeks.

At Linaro, the Linaro Developer Platform team will be organizing an ARM porting Jam this Friday, with the goal of getting all developers interested in fixing and working on bugs and portability issues related with the Ubuntu ARM port (mostly issues with ARMHF at the moment).

The idea of having the Porting Jam at Friday is to have it as a joint effort with Ubuntu’s Fix Friday and Ubuntu Global Jam, so expect quite a few other developers helping improving Ubuntu as well!

It’s quite easy to participate:

Remember that for ARM this release will be a quite huge milestone, as it’ll be the first LTS release supporting ARM, besides delivering support for ARM servers and ARMHF as default, so let’s make sure it rocks!

Looking forward for a great porting Jam!

Happy bug fixing!

Read more

Yesterday Canonical announced the first UI concept for the Ubuntu TV. Together with the announcement, the first code drop was released, so we could read and understand better the technologies used, and how this will behave on an ARM environment, mostly at a Pandaboard (that we already have OpenGL ES 2 and video decode working).

Getting Ubuntu TV to work

If are still using Oneiric, you can just follow the guide presented at, where you’ll find all needed steps to try Ubuntu TV at your machine.

As it’s quite close with Unity 2D (similar code base), and also based on Qt, I decided to follow the steps described at wiki page and see if it should work correctly.

First issue we found with Qt, was that it wasn’t rendering at full screen when using with latest PowerVR SGX drivers, so any application you wanted to use with Qt Opengl would just show itself on a small part of the screen. Luckily TI (Nicolas Dechesne and Xavier Boudet) quickly provided me a new release of the driver, fixing this issue (version that should be around later today at the Linaro Overlay), so I could continue my journey :-)

Next problem was that Qt was enabling brokenTexSubImage and brokenFBOReadBack for the SGX drivers based on the old versions available for Beagle, and seems this is not needed anymore with the current version available at Pandaboard (still to be reviewed with TI, so a proper solution can be forwarded to Qt).

Code removed, patch applied and package built (after many hours), and I was finally able to successfully open the Ubuntu TV interface at my Panda :-)

UI Navigation on a Pandaboard, with Qt and OpenGL ES2.0

Running Ubuntu TV is quite simple if you’re already running the Unity 2D interface. All you need to do is to make sure you kill all unity-2d components and that you’re running metacity without composite enabled. Other than that you just run ”unity-2d-shell -opengl” and voilà ;-)

Here’s a video of the current interface running on my Panda:

As you can see from the video, I didn’t actually play any video, and that’s because currently we’re lacking a generic texture handler for OpenGL ES with Gstreamer at Qtmobility (there’s only one available, but specifically for Meego). Once that’s fixed, the video playback should behave similarly as with XBMC (but with less hacks, as it’s a native GST backend).

Next steps, enabling proper video decode

Looking at what would be needed to finally be able to play the videos, and to make it something useful at your Pandaboard, the first thing is that we need to improve Qtmobility to have a more generic (but unfortunately still specific to Omap) way handle texture streaming with Gstreamer and OpenGL ES. Rob Clark added a similar functionality at XBMC, creating support for ”eglImage”, so we just need to port the work and make sure it works properly with Qtmobility.

Once that’s ported, the video should be streamed as a texture at the video surface, making it also work transparently with QML (the way it’s done with Ubuntu TV).

If you know Qt and Gstreamer, and also want to help getting it to work properly on your panda, here follows a few resources:

As soon video decoding is working properly, a new blog post should be around explaining the details and how to reproduce it at your own Panda with Ubuntu LEB :-)


Read more

As described on my previous post about Ubuntu TV support on a Pandaboard, we were still missing proper support for texture streaming on a Pandaboard, to have the video playback also working and fully accelerated.

This weekend Rob Clark managed to create the first version of the TI’s specific eglImage support at Qtmobility, posting the code at his gitorious account, and for the first time we’re fully able to use Ubuntu TV on a ARM device, using a Pandaboard.

Demo video with the Ubuntu TV UI (accelerated with Qt and OpenGL ES 2.0) and with video decode support of 720p and 1080p:

The code support for TI’s eglImage still needs a few clean-ups, but we hope to be able to push the support at Ubuntu in the following weeks (make it good enough to try at least a package patch).

For people wanting to try it out, a few packages are already available at Linaro’s Overlay PPA, and the remaining ones should be available later today (Qt and Qtmobility), so people can easily run it with our images.

Hope you enjoy, and we’ll make sure we’re always working on keeping and improving the current support, so Ubuntu TV also rocks with ARM :-)


Read more

During the end of October and beginning of November we had the last Linaro Connect for the year. This time we also had it together with the Ubuntu Developer Summit, giving us the opportunity to better discuss the roadmap with both Linaro and the Ubuntu team.

From the Developer Platform team perspective, we had a quite nice week, with demos happening at Monday and Friday (showing people what we’ve been working on), and also sharing some great news with the Ubuntu team, now that Mark Shuttleworth announced that Ubuntu will go to Tablets, TVs and Phones (and ARM for sure will be a huge part of that).

Some nice links and videos of what happened during that week (related with our team):
* Sessions related with the Developer Platform Team (Ubuntu)
* Linaro Demo: Ubuntu Unity with OpenGL ES on Pandaboard
* Linaro Developer Platform Tech Lead Ricardo Salveti Interview at Linaro Connect
* Linaro Connect Q4.11 – Ubuntu LEB tutorial
* Linaro Connect Q4.11 – Interview with Marcin Juszkiewicz

Linaro 11.11 Release

Another quite good achievement for us during November was the 11.11 release.

During this release we had a quite a few great highlights, including some that we were planning for quite a while already:
* Ability to cross build Firefox using Multiarch
* OMAP4 SPL USB Booting, enabling USB boot at Pandaboard
* ARM DS-5 support for the 5.8 release
* CI Builds for Linaro GCC both for cross and native
* And a lot of bug fixes

Now it’s time to get ready to develop the blueprints we’re planning for 11.12, to also make December another great and solid month :-) (will do another post about the 11.12 planning later this one).

Read more
Chris Kenyon

HP logo


Today HP announced Project Moonshot  - a programme to accelerate the use of low power processors in the data centre.

The three elements of the announcement are the launch of Redstone – a development platform that harnesses low-power processors (both ARM & x86),  the opening of the HP Discovery lab in Houston and the Pathfinder partnership programme.

Canonical is delighted to be involved in all three elements of HP’s Moonshot programme to reduce both power and complexity in data centres.

The HP Redstone platform unveiled in Palo Alto showcases HP’s thinking around highly federated environments and Calxeda’s EnergyCore ARM processors. The Calxeda system on chip (SoC) design is powered by Calxeda’s own ARM based processor and combines mobile phone like power consumption with the attributes required to run a tangible proportion of hyperscale data centre workloads.

HP Redstone Platform

The promise of server grade SoC’s running at less than 5W and achieving per rack density of 2800+ nodes is impressive, but what about the software stacks that are used to run the web and analyse big data – when will they be ready for this new architecture?

Ubuntu Server is increasingly the operating system of choice for web, big data and cloud infrastructure workloads. Films like Avatar are rendered on Ubuntu, Hadoop is run on it and companies like Rackspace and HP are using Ubuntu Server as the foundation of their public cloud offerings.

The good news is that Canonical has been working with ARM and Calexda for several years now and we released the first version of Ubuntu Server ported for ARM Cortex A9 class  processors last month.

The Ubuntu 11.10 release (download) is an functioning port and over the next six months and we will be working hard to benchmark and optimize Ubuntu Server and the workloads that our users prioritize on ARM.  This work, by us and by upstream open source projects is going to be accelerated by today’s announcement and access to hardware in the HP Discovery lab.

As HP stated today, this is beginning of a journey to re-inventing a power efficient and less complex data center. We look forward to working with HP and Calxeda on that journey.


Read more
Dustin Kirkland

for Ubuntu Servers

I've long had a personal interest in the energy efficiency of the Ubuntu Server.  This interest has manifested in several ways.  From founding the PowerNap Project to using tiny netbooks and notebooks as servers, I'm just fascinated with the idea of making computing more energy efficient.

It wasn't so long ago, in December 2008 at UDS-Jaunty in Mountain View that I proposed just such a concept, and was nearly ridiculed out of the room.  (Surely no admin in his right mind would want enterprise infrastructure running on ARM processors!!! ...  Um, well, yeah, I do, actually....)  Just a little over two years ago, in July 2009, I longed for the day when Ubuntu ARM Servers might actually be a reality...

My friends, that day is here at last!  Ubuntu ARM Servers are now quite real!

The affable Chris Kenyon first introduced the world to Canonical's efforts in this space with his blog post, Ubuntu Server for ARM Processors a little over a week ago.  El Reg picked up the story quickly, and broke the news in Canonical ARMs Ubuntu for microserver wars.   And ZDNet wasn't far behind, running an article this week, Ubuntu Linux bets on the ARM server.  So the cat is now officially out of the bag -- Ubuntu Servers on ARM are here :-)

Looking for one?  This article covers David Mandala's 42-core ARM cluster, based around TI Panda boards.  I also recently came across the ZT Systems R1801e Server, boasting 8 x Dual ARM Cortex A9 processors.  The most exciting part is that this is just the tip of the iceberg.  We've partnered with companies like Calxeda (here in Austin) and others to ensure that the ARM port of the Ubuntu Server will be the most attractive OS option for quite some time.

A huge round of kudos goes to the team of outstanding engineers at Canonical (and elsewhere) doing this work.  I'm sure I'm leaving off a ton of people (feel free to leave comments about who I've missed), but the work that's been most visible to me has been by:

So I'm looking forward to reducing my servers' energy footprint...are you?


Read more

Over the past month I’ve being working with John Rigby to integrate the SMSC95XX and OMAP4 EHCI patches into Linaro U-Boot, so we could deliver the network booting feature for people using Pandaboards.

Those patches are published at the U-Boot mailing list, but still as a working in progress. While we work helping the original developers to get the patches accepted upstream, we also want to deliver the functionality for our users, so all those patches are now integrated at the Linaro U-Boot tree.

You can check the patches by going at;a=shortlog.

Testing with Pandaboard

To make it work properly, besides using Linaro U-Boot you’ll also need to use the upstream X-Loader tree, with one additional patch that’s not yet merged. You can clone the upstream tree from, then just apply the patch and build for the Pandaboard target.

If you just want to test without building your own X-Loader and U-Boot, you can just grab both files from

Building your TFTP + DHCP server for PXE

To build your TFTP + DCHP server just follow the instructions described at Don’t worry about the ‘filename “pxelinux.0”;’ line at the dhcpd.conf file, you can remove it.

Then just create your PXE config file at the right place:

$ cat /tftpboot/pxelinux.cfg/0A2A2B0A
default panda-natty
prompt 0
timeout 3

label panda-natty
kernel panda/uImage
append console=ttyO2,115200n8 root=/dev/mmcblk0p2 ro fixrtc vram=48M omapfb.vram=0:24M mem=1G@0x80000000 text earlyprintk=ttyO2
initrd panda/uInitrd

PXE Booting

With the proper X-Loader and U-Boot files in place (at your first SD card partition), and with the TFTP + DHCP server also properly installed, you can just jump and try TFTP/PXE boot.

Stop the U-Boot autoload and call the following commands:

  • setenv pxecfg_ram 0x88000000: location in RAM to load the pxecfg file
  • setenv kernel_ram 0x80000000: location in RAM to load the kernel
  • setenv initrd_ram 0x81600000: location in RAM to load the initrd
  • setenv autoload no: disable autoload while calling bootp (so you can just set up your network without autoboot)
  • usb start: start USB and enables the SMSC95xx ethernet interface
  • bootp: initialize the network, probing the ip address settings from your DHCP server
  • pxecfg get: probe the pxecfg config file
  • pxecfg boot: boot :-)

You should get a similar output as:

Texas Instruments X-Loader 1.5.0 (Jul 11 2011 – 07:52:49)
Reading boot sector
Loading u-boot.bin from mmc

U-Boot 2011.06 (Jul 11 2011 – 02:49:51)

CPU : OMAP4430
Board: OMAP4 Panda
I2C: ready
Using default environment

In: serial
Out: serial
Err: serial
Net: No ethernet found.
Hit any key to stop autoboot: 0
Panda # setenv pxecfg_ram 0x88000000
Panda # setenv kernel_ram 0x80000000
Panda # setenv initrd_ram 0x81600000
Panda # setenv autoload no
Panda # usb start
(Re)start USB…
USB: Register 1313 NbrPorts 3
scanning bus for devices… The request port(2) is not configured
EHCI timed out on TD – token=0x80008c80
The request port(2) is not configured
4 USB Device(s) found
scanning bus for storage devices… 0 Storage Device(s) found
scanning bus for ethernet devices… 1 Ethernet Device(s) found
Panda # bootp
Waiting for Ethernet connection… done.
BOOTP broadcast 1
DHCP client bound to address
Panda # pxecfg get
missing environment variable: pxeuuid
missing environment variable: ethaddr
Retreiving file: pxelinux.cfg/0A2A2B0A
Waiting for Ethernet connection… done.
Using sms0 device
TFTP from server; our IP address is
Filename ‘pxelinux.cfg/0A2A2B0A’.
Load address: 0x88000000
Loading: #
Bytes transferred = 239 (ef hex)
Config file found
Panda # pxecfg boot
Hit any key to stop autoboot: 0
Label: panda-natty
kernel: panda/uImage
append: console=ttyO2,115200n8 root=/dev/mmcblk0p2 ro fixrtc vram=48M omapfb.vram=0:24M mem=1G@0x80000000 text earlyprintk=ttyO2
initrd: panda/uInitrd
Retreiving file: panda/uInitrd
Waiting for Ethernet connection… done.
Using sms0 device
TFTP from server; our IP address is
Filename ‘panda/uInitrd’.
Load address: 0x81600000
Loading: #################################################################
Bytes transferred = 3982715 (3cc57b hex)
Retreiving file: panda/uImage
Waiting for Ethernet connection… done.
Using sms0 device
TFTP from server; our IP address is
Filename ‘panda/uImage’.
Load address: 0x80000000
Loading: #################################################################
Bytes transferred = 4174480 (3fb290 hex)
## Booting kernel from Legacy Image at 80000000 …
Image Name: Ubuntu Kernel
Image Type: ARM Linux Kernel Image (uncompressed)
Data Size: 4174416 Bytes = 4 MiB
Load Address: 80008000
Entry Point: 80008000
Verifying Checksum … OK
## Loading init Ramdisk from Legacy Image at 81600000 …
Image Name: Ubuntu Initrd
Image Type: ARM Linux RAMDisk Image (uncompressed)
Data Size: 3982651 Bytes = 3.8 MiB
Load Address: 00000000
Entry Point: 00000000
Verifying Checksum … OK
Loading Kernel Image … OK

Starting kernel …

Uncompressing Linux… done, booting the kernel.
[ 0.000000] Initializing cgroup subsys cpuset
[ 0.000000] Initializing cgroup subsys cpu

This should be enough for you to get your Pandaboard booting with PXE. You can also script these commands at your boot.scr file that U-Boot loads automatically from your SD card, so you don’t have to call them by hand every time you reboot your board.

In case it doesn’t work for you, just ping me (rsalveti) at #linaro on freenode :-)

Read more

As discussed at last months Ubuntu Developer Summit in the session ‘ARM and other architectures certification program‘, there’s a plan to start certifying ARM hardware, or at least start investigating how we’ll do it. To this end I’ve received on loan a TI OMAP4 Pandaboard from Canonical’s ARM QA team. I’ve actually had it here in the office for quite a few weeks now but for some reason or another I haven’t got around to blogging about it yet!

So, without further adieu – here are a couple of shots of my setup:

I like it because it’s really compact and smacks of geekiness, with all the exposed circuits, yet is really quite easy to use in a lot of ways. The monitor is plugged in via the HDMI port on the right hand side (because of an issue with my monitor I can only get 640×480 out of it, so everything is very squeezed on the screen) and the wireless desktop receiver which handles my mouse and keyboard plugs right in to one of the two full sized USB 2.0 ports. The whole thing is powered by my laptop (even when it’s suspended) via USB-AC 5v connector, also on the right-hand side.

It’s running Natty/Unity 2D installed on the 8GB SDHC card on the left of the board. This means that the whole setup cost (if I had have payed for rather than borrowed it) just under $200. The white labeled chip on the top left hand side of the board is the WiFi/Bluetooth chip and that works *perfectly* out of the box – often picking up a better signal than the laptop sitting right next to it. I also have the option of plugging in my USB headset in the the same USB hub as the wireless receiver (it’s a tight squeeze but it just about fits) and that too works perfectly.

Cons are that I don’t have a USB HDD so Ubuntu is running on flash memory (notoriously bad performance) and that if I decide to power down my laptop but forget the Pandaboard has some task running on it then all is lost :( Overall though it’s a really nice piece of equipment and because of all the good work that has been done around it, I could recommend one to anyone with a bit of technical know-how (no ARM experience required!)

Read more
